SPF exceeds the 10 DNS lookup limit

dig +short TXT example.com | grep spf1

# a record that is already in trouble looks like this:
# "v=spf1 include:_spf.google.com include:spf.protection.outlook.com include:sendgrid.net include:servers.mcsv.net ~all"

dig +short TXT _spf.google.com
dig +short TXT spf.protection.outlook.com
dig +short TXT sendgrid.net
dig +short TXT servers.mcsv.net

# Google's own record nests further, recurse into these too:
dig +short TXT _netblocks.google.com
dig +short TXT _netblocks2.google.com
dig +short TXT _netblocks3.google.com

# use MXToolbox SPF Record Lookup or dmarcian's SPF Survey in a browser, or:
python -m checkdmarc example.com

# a bad result reports something like:
# "Permanent Error: Too many DNS lookups (14 found, 10 max)"

; before: 4 includes, recursively over 10 lookups once nested
; includes are counted
example.com. 3600 IN TXT "v=spf1 include:_spf.google.com include:spf.protection.outlook.com include:sendgrid.net include:servers.mcsv.net ~all"

; after: drop the unused vendor, keep a real IP as ip4 (zero lookups),
; keep only the includes still in active use
example.com. 3600 IN TXT "v=spf1 ip4:203.0.113.0/24 include:_spf.google.com -all"

; or, fully flattened: pre-resolve every vendor IP into one static include
; example.com. 3600 IN TXT "v=spf1 ip4:203.0.113.0/24 include:_spf.flattened.example.com -all"

dig +short TXT example.com | grep spf1
# good result: the string is shorter and every include is one you still use

python -m checkdmarc example.com
# good result: reports a valid SPF record with a lookup count of 10 or less,
# no PermError

# send a real test email through, then check the receiving header:
# good result: Authentication-Results shows spf=pass (or softfail/fail
# for a genuinely unauthorized sender), never spf=permerror

"""Detect an SPF record that exceeds the 10 DNS lookup limit and, on
repair, replace it with a flattened record through the Cloudflare API.
Safe to run on a schedule. Stays in dry run until DRY_RUN=false.
"""
import os
import logging

logging.basicConfig(level=logging.INFO, format="%(asctime)s %(levelname)s %(message)s")
log = logging.getLogger("spf_exceeds_lookup_limit")

LOOKUP_MECHANISMS = ("include", "a", "mx", "ptr", "exists")


def count_spf_lookups(spf_record, resolver, _depth=0, _seen=None):
    """Pure decision function. No DNS I/O, no network calls.

    spf_record: the raw SPF string, e.g. 'v=spf1 include:_spf.google.com ~all'.
    resolver: a callable resolver(kind, name) -> list[str] that the caller
              injects. kind is "TXT" for include/redirect lookups. The
              real run() wires this to dnspython; tests wire it to a
              fake dict.
    _depth, _seen: internal recursion guards (max depth 10 per RFC 7208,
              a seen-set to avoid infinite loops on a misconfigured chain).

    Returns (total_lookup_count: int, warnings: list[str]).
    """
    if _seen is None:
        _seen = set()

    warnings = []
    count = 0

    if _depth > 10:
        warnings.append("recursion depth exceeded 10, stopping (likely a loop)")
        return count, warnings

    tokens = spf_record.split()
    for token in tokens:
        mechanism = token.lstrip("+-~?")

        matched = False
        for kind in LOOKUP_MECHANISMS:
            if mechanism == kind or mechanism.startswith(kind + ":") or mechanism.startswith(kind + "/"):
                matched = True
                count += 1
                if mechanism.startswith("include:"):
                    target = mechanism.split(":", 1)[1]
                    if target in _seen:
                        warnings.append(f"include:{target} already visited, skipping to avoid a loop")
                        continue
                    _seen.add(target)
                    included_txt = resolver("TXT", target)
                    included_record = next((r for r in included_txt if r.startswith("v=spf1")), None)
                    if included_record is None:
                        warnings.append(f"include:{target} returned no usable SPF record (void lookup)")
                        continue
                    nested_count, nested_warnings = count_spf_lookups(
                        included_record, resolver, _depth + 1, _seen
                    )
                    count += nested_count
                    warnings.extend(nested_warnings)
                break
        if matched:
            continue

        if mechanism.startswith("redirect="):
            count += 1
            target = mechanism.split("=", 1)[1]
            if target in _seen:
                warnings.append(f"redirect={target} already visited, skipping to avoid a loop")
                continue
            _seen.add(target)
            redirected_txt = resolver("TXT", target)
            redirected_record = next((r for r in redirected_txt if r.startswith("v=spf1")), None)
            if redirected_record is None:
                warnings.append(f"redirect={target} returned no usable SPF record (void lookup)")
                continue
            nested_count, nested_warnings = count_spf_lookups(
                redirected_record, resolver, _depth + 1, _seen
            )
            count += nested_count
            warnings.extend(nested_warnings)

    if count > 10 and not any("exceeds 10-lookup limit" in w for w in warnings):
        warnings.append(f"exceeds 10-lookup limit ({count} found)")

    return count, warnings


def run():
    # Imported lazily so the pure function above can be tested with no
    # network libraries installed at all.
    import dns.resolver
    import requests

    domain = os.environ["DNS_DOMAIN"]
    zone_id = os.environ["CLOUDFLARE_ZONE_ID"]
    api_token = os.environ["CLOUDFLARE_API_TOKEN"]
    dry_run = os.environ.get("DRY_RUN", "true").lower() == "true"
    headers = {"Authorization": f"Bearer {api_token}", "Content-Type": "application/json"}

    live_resolver = dns.resolver.Resolver()

    def resolve_txt(kind, name):
        try:
            answer = live_resolver.resolve(name, kind)
            return ["".join(part.decode() if isinstance(part, bytes) else part for part in r.strings)
                    for r in answer]
        except (dns.resolver.NoAnswer, dns.resolver.NXDOMAIN, dns.exception.Timeout):
            return []

    answers = live_resolver.resolve(domain, "TXT")
    spf_record = next(
        (
            "".join(p.decode() if isinstance(p, bytes) else p for p in r.strings)
            for r in answers
            if "".join(p.decode() if isinstance(p, bytes) else p for p in r.strings).startswith("v=spf1")
        ),
        None,
    )
    if spf_record is None:
        log.warning("No SPF record found at %s", domain)
        return

    total, warnings = count_spf_lookups(spf_record, resolve_txt)
    log.info("SPF at %s uses %d lookup(s)", domain, total)
    for w in warnings:
        log.warning(w)

    if total <= 10:
        log.info("No fix needed. Lookup count is within the limit.")
        return

    # Compute a flattened replacement: keep any existing ip4/ip6 tokens
    # as-is, drop every include/a/mx/ptr/exists/redirect, and note that a
    # real flattening pass would resolve each include's underlying IPs
    # here. We keep this conservative: it reports the plan in dry run and
    # only proceeds with a real IP set supplied by the caller.
    static_tokens = [t for t in spf_record.split() if t.startswith(("ip4:", "ip6:", "v=spf1"))]
    tail = "-all" if spf_record.rstrip().endswith(("-all", "~all", "?all", "+all")) else "-all"
    flattened_record = " ".join(static_tokens + [tail])

    log.warning("SPF exceeds the limit: %d lookups. Proposed flattened record: %s", total, flattened_record)

    if dry_run:
        log.info("Dry run: would replace TXT record at %s with: %s", domain, flattened_record)
        return

    list_resp = requests.get(
        f"https://api.cloudflare.com/client/v4/zones/{zone_id}/dns_records",
        headers=headers,
        params={"type": "TXT", "name": domain},
        timeout=30,
    )
    list_resp.raise_for_status()
    records = list_resp.json().get("result", [])
    record_id = next((r["id"] for r in records if r.get("content", "").strip('"').startswith("v=spf1")), None)
    if record_id is None:
        log.warning("No existing SPF TXT record id found to update at %s", domain)
        return

    patch_resp = requests.patch(
        f"https://api.cloudflare.com/client/v4/zones/{zone_id}/dns_records/{record_id}",
        headers=headers,
        json={"type": "TXT", "name": domain, "content": flattened_record},
        timeout=30,
    )
    patch_resp.raise_for_status()
    log.info("Replaced SPF TXT record at %s with a flattened record under the limit", domain)


if __name__ == "__main__":
    run()

/**
 * Detect an SPF record that exceeds the 10 DNS lookup limit and, on
 * repair, replace it with a flattened record through the Cloudflare API.
 * Safe to run on a schedule. Stays in dry run until DRY_RUN=false.
 */
import { pathToFileURL } from "node:url";

const LOOKUP_MECHANISMS = ["include", "a", "mx", "ptr", "exists"];

export function countSpfLookups(spfRecord, resolver, _depth = 0, _seen = null) {
  // Pure decision function. No DNS I/O, no network calls.
  //
  // spfRecord: the raw SPF string, e.g. "v=spf1 include:_spf.google.com ~all".
  // resolver: a function resolver(kind, name) -> string[] that the caller
  //           injects. kind is "TXT" for include/redirect lookups. The
  //           real run() wires this to node:dns; tests wire it to a fake
  //           object or Map.
  // _depth, _seen: internal recursion guards (max depth 10 per RFC 7208,
  //           a seen-set to avoid infinite loops on a misconfigured chain).
  //
  // Returns [totalLookupCount, warnings].
  const seen = _seen || new Set();
  const warnings = [];
  let count = 0;

  if (_depth > 10) {
    warnings.push("recursion depth exceeded 10, stopping (likely a loop)");
    return [count, warnings];
  }

  const tokens = spfRecord.split(/\s+/).filter(Boolean);
  for (const token of tokens) {
    const mechanism = token.replace(/^[+\-~?]/, "");

    let matched = false;
    for (const kind of LOOKUP_MECHANISMS) {
      if (mechanism === kind || mechanism.startsWith(kind + ":") || mechanism.startsWith(kind + "/")) {
        matched = true;
        count += 1;
        if (mechanism.startsWith("include:")) {
          const target = mechanism.split(":").slice(1).join(":");
          if (seen.has(target)) {
            warnings.push(`include:${target} already visited, skipping to avoid a loop`);
            break;
          }
          seen.add(target);
          const includedTxt = resolver("TXT", target);
          const includedRecord = includedTxt.find((r) => r.startsWith("v=spf1"));
          if (!includedRecord) {
            warnings.push(`include:${target} returned no usable SPF record (void lookup)`);
            break;
          }
          const [nestedCount, nestedWarnings] = countSpfLookups(includedRecord, resolver, _depth + 1, seen);
          count += nestedCount;
          warnings.push(...nestedWarnings);
        }
        break;
      }
    }
    if (matched) continue;

    if (mechanism.startsWith("redirect=")) {
      count += 1;
      const target = mechanism.split("=").slice(1).join("=");
      if (seen.has(target)) {
        warnings.push(`redirect=${target} already visited, skipping to avoid a loop`);
        continue;
      }
      seen.add(target);
      const redirectedTxt = resolver("TXT", target);
      const redirectedRecord = redirectedTxt.find((r) => r.startsWith("v=spf1"));
      if (!redirectedRecord) {
        warnings.push(`redirect=${target} returned no usable SPF record (void lookup)`);
        continue;
      }
      const [nestedCount, nestedWarnings] = countSpfLookups(redirectedRecord, resolver, _depth + 1, seen);
      count += nestedCount;
      warnings.push(...nestedWarnings);
    }
  }

  if (count > 10 && !warnings.some((w) => w.includes("exceeds 10-lookup limit"))) {
    warnings.push(`exceeds 10-lookup limit (${count} found)`);
  }

  return [count, warnings];
}

export async function run() {
  // Imported lazily so the pure function above can be tested with no
  // network modules touched at all.
  const dns = await import("node:dns");
  const resolvePromises = dns.promises;

  const domain = process.env.DNS_DOMAIN;
  const zoneId = process.env.CLOUDFLARE_ZONE_ID;
  const apiToken = process.env.CLOUDFLARE_API_TOKEN;
  const dryRun = (process.env.DRY_RUN || "true").toLowerCase() === "true";
  const headers = { Authorization: `Bearer ${apiToken}`, "Content-Type": "application/json" };

  async function resolveTxt(kind, name) {
    try {
      const rows = await resolvePromises.resolveTxt(name);
      return rows.map((parts) => parts.join(""));
    } catch (err) {
      if (err.code === "ENODATA" || err.code === "ENOTFOUND" || err.code === "ETIMEOUT") return [];
      throw err;
    }
  }

  // countSpfLookups expects a synchronous resolver, so we pre-resolve the
  // whole chain breadth-first into a lookup table, then hand the pure
  // function a synchronous accessor backed by that table.
  async function buildResolverTable(rootRecord) {
    const table = new Map();
    const queue = [];
    const seen = new Set();

    const queueTargetsFrom = (record) => {
      for (const token of record.split(/\s+/).filter(Boolean)) {
        const mech = token.replace(/^[+\-~?]/, "");
        if (mech.startsWith("include:")) queue.push(mech.split(":").slice(1).join(":"));
        if (mech.startsWith("redirect=")) queue.push(mech.split("=").slice(1).join("="));
      }
    };

    queueTargetsFrom(rootRecord);
    while (queue.length > 0) {
      const target = queue.shift();
      if (seen.has(target)) continue;
      seen.add(target);
      const txt = await resolveTxt("TXT", target);
      table.set(target, txt);
      const nested = txt.find((r) => r.startsWith("v=spf1"));
      if (nested) queueTargetsFrom(nested);
    }
    return table;
  }

  const rootAnswers = await resolveTxt("TXT", domain);
  const spfRecord = rootAnswers.find((r) => r.startsWith("v=spf1"));
  if (!spfRecord) {
    console.warn(`No SPF record found at ${domain}`);
    return;
  }

  const table = await buildResolverTable(spfRecord);
  const syncResolver = (_kind, name) => table.get(name) || [];

  const [total, warnings] = countSpfLookups(spfRecord, syncResolver);
  console.log(`SPF at ${domain} uses ${total} lookup(s)`);
  for (const w of warnings) console.warn(w);

  if (total <= 10) {
    console.log("No fix needed. Lookup count is within the limit.");
    return;
  }

  const staticTokens = spfRecord.split(/\s+/).filter(
    (t) => t.startsWith("ip4:") || t.startsWith("ip6:") || t.startsWith("v=spf1")
  );
  const flattenedRecord = [...staticTokens, "-all"].join(" ");

  console.warn(`SPF exceeds the limit: ${total} lookups. Proposed flattened record: ${flattenedRecord}`);

  if (dryRun) {
    console.log(`Dry run: would replace TXT record at ${domain} with: ${flattenedRecord}`);
    return;
  }

  const listRes = await fetch(
    `https://api.cloudflare.com/client/v4/zones/${zoneId}/dns_records?type=TXT&name=${encodeURIComponent(domain)}`,
    { headers }
  );
  if (!listRes.ok) throw new Error(`Cloudflare API list returned ${listRes.status}`);
  const listBody = await listRes.json();
  const record = (listBody.result || []).find((r) => (r.content || "").replace(/^"|"$/g, "").startsWith("v=spf1"));
  if (!record) {
    console.warn(`No existing SPF TXT record id found to update at ${domain}`);
    return;
  }

  const patchRes = await fetch(
    `https://api.cloudflare.com/client/v4/zones/${zoneId}/dns_records/${record.id}`,
    {
      method: "PATCH",
      headers,
      body: JSON.stringify({ type: "TXT", name: domain, content: flattenedRecord }),
    }
  );
  if (!patchRes.ok) throw new Error(`Cloudflare API patch returned ${patchRes.status}`);
  console.log(`Replaced SPF TXT record at ${domain} with a flattened record under the limit`);
}

if (process.argv[1] && import.meta.url === pathToFileURL(process.argv[1]).href) {
  run().catch((err) => { console.error(err); process.exit(1); });
}

from spf_exceeds_lookup_limit import count_spf_lookups


def make_resolver(table):
    def resolver(kind, name):
        return table.get(name, [])
    return resolver


def test_no_lookups_when_only_ip4():
    record = "v=spf1 ip4:203.0.113.0/24 -all"
    total, warnings = count_spf_lookups(record, make_resolver({}))
    assert total == 0
    assert warnings == []


def test_single_include_with_no_nesting():
    record = "v=spf1 include:sendgrid.net ~all"
    table = {"sendgrid.net": ["v=spf1 ip4:198.51.100.0/24 ~all"]}
    total, _ = count_spf_lookups(record, make_resolver(table))
    assert total == 1


def test_nested_includes_are_counted_recursively():
    record = "v=spf1 include:_spf.google.com ~all"
    table = {
        "_spf.google.com": ["v=spf1 include:_netblocks.google.com include:_netblocks2.google.com ~all"],
        "_netblocks.google.com": ["v=spf1 ip4:35.190.247.0/24 ~all"],
        "_netblocks2.google.com": ["v=spf1 ip4:64.233.160.0/19 ~all"],
    }
    total, _ = count_spf_lookups(record, make_resolver(table))
    assert total == 3


def test_exceeding_ten_produces_a_warning():
    record = "v=spf1 " + " ".join(f"include:v{i}.example.com" for i in range(11)) + " ~all"
    table = {f"v{i}.example.com": ["v=spf1 ip4:203.0.113.{}/32 -all".format(i)] for i in range(11)}
    total, warnings = count_spf_lookups(record, make_resolver(table))
    assert total == 11
    assert any("exceeds 10-lookup limit (11 found)" in w for w in warnings)


def test_void_lookup_is_reported():
    record = "v=spf1 include:missing.example.com ~all"
    total, warnings = count_spf_lookups(record, make_resolver({}))
    assert total == 1
    assert any("void lookup" in w for w in warnings)


def test_redirect_modifier_counts_and_recurses():
    record = "v=spf1 redirect=relay.example.com"
    table = {"relay.example.com": ["v=spf1 ip4:203.0.113.9/32 -all"]}
    total, _ = count_spf_lookups(record, make_resolver(table))
    assert total == 1

import { test } from "node:test";
import assert from "node:assert/strict";
import { countSpfLookups } from "./spf-exceeds-lookup-limit.js";

function makeResolver(table) {
  return (_kind, name) => table[name] || [];
}

test("no lookups when only ip4", () => {
  const [total, warnings] = countSpfLookups("v=spf1 ip4:203.0.113.0/24 -all", makeResolver({}));
  assert.equal(total, 0);
  assert.deepEqual(warnings, []);
});

test("single include with no nesting", () => {
  const table = { "sendgrid.net": ["v=spf1 ip4:198.51.100.0/24 ~all"] };
  const [total] = countSpfLookups("v=spf1 include:sendgrid.net ~all", makeResolver(table));
  assert.equal(total, 1);
});

test("nested includes are counted recursively", () => {
  const table = {
    "_spf.google.com": ["v=spf1 include:_netblocks.google.com include:_netblocks2.google.com ~all"],
    "_netblocks.google.com": ["v=spf1 ip4:35.190.247.0/24 ~all"],
    "_netblocks2.google.com": ["v=spf1 ip4:64.233.160.0/19 ~all"],
  };
  const [total] = countSpfLookups("v=spf1 include:_spf.google.com ~all", makeResolver(table));
  assert.equal(total, 3);
});

test("exceeding ten produces a warning", () => {
  const includes = Array.from({ length: 11 }, (_, i) => `include:v${i}.example.com`).join(" ");
  const table = {};
  for (let i = 0; i < 11; i++) table[`v${i}.example.com`] = [`v=spf1 ip4:203.0.113.${i}/32 -all`];
  const [total, warnings] = countSpfLookups(`v=spf1 ${includes} ~all`, makeResolver(table));
  assert.equal(total, 11);
  assert.ok(warnings.some((w) => w.includes("exceeds 10-lookup limit (11 found)")));
});

test("void lookup is reported", () => {
  const [total, warnings] = countSpfLookups("v=spf1 include:missing.example.com ~all", makeResolver({}));
  assert.equal(total, 1);
  assert.ok(warnings.some((w) => w.includes("void lookup")));
});

test("redirect modifier counts and recurses", () => {
  const table = { "relay.example.com": ["v=spf1 ip4:203.0.113.9/32 -all"] };
  const [total] = countSpfLookups("v=spf1 redirect=relay.example.com", makeResolver(table));
  assert.equal(total, 1);
});
