Diagnostic GitHub API

the installation covers only some repositories, silently

The scanner reports clean. Every repository it looked at was fine, every check passed, and the summary at the bottom says so. It looked at twelve repositories. The organization has a hundred and forty. Nothing errored, nothing warned, and no line of that report is untrue — the App installation was set to selected repositories at some point in 2023 and the other hundred and twenty-eight have never been inside its field of view.

Read-only token Python and Node.js Tests included
Two smiling men holding "service &" and "expertise" signs.
Photo by Md Ishak Rahman on Unsplash
The short answer

GET /installation/repositories returns repository_selection and total_count. When the selection is selected, that count is the size of the App's world, not the size of the organization's.

Get the second number independently — GET /orgs/{org} gives public_repos plus total_private_repos — and compare. The gap is the finding, and it is the only way an audit can state its own coverage instead of assuming it.

The problem in plain words

Partial coverage is the most expensive kind of wrong answer because it looks exactly like a right one. A scanner that crashes gets fixed on Tuesday. A scanner that reports "0 findings across 12 repositories" gets a green tick, and the number 12 sits in a line nobody reads next to the number that everybody reads.

It also drifts in one direction only. Somebody installs the App on three repositories to try it, it works, it goes to production, and every repository created afterwards is outside it. A selected installation does not grow: new repositories are not added automatically, so the gap between what the App sees and what exists widens every time the organization ships something new.

App installedin 2023selectedrepositories140 repos existnow12 were evertickedAudit listswhat it sees12 rows, no errorSummary saysall clearacross 12 of 140128 neverscannednobody asked aboutthem
No truncation flag, no warning and no error. The response is correct; the question was smaller than anyone thought.

Why it happens

repository_selection has exactly two values and only one of them is safe to assume. all means the installation follows the account, including repositories created tomorrow. selected means a fixed list chosen by whoever clicked through the installation screen, possibly years ago, possibly in a hurry.

The API is not lying, which is why nothing detects it. Every list endpoint under an installation token returns a complete answer for the installation's scope. There is no truncation flag, no incomplete_results, no header. The response is correct; it is the question that was smaller than anyone thought.

The comparison needs a number from outside the installation. This is the part that makes it real work: nothing inside the App's own view can tell it what it is missing. You need the organization's repository count from GET /orgs/{org}, or the last page number from a Link header on GET /orgs/{org}/repos?per_page=1, and both of those need a credential that can see the whole organization.

That outside number is itself sometimes unavailable. total_private_repos on the organization object is only returned to callers with enough access. Without it, the public count alone is a floor, not a total — and a coverage figure computed from a floor understates the gap, which is worse than reporting no figure at all.

The fix, as a flow

The script needs a number from outside the App, because nothing inside an installation can tell you what the installation is missing. Every endpoint under it is answering completely, about a smaller world.

Installation count vs orgcountone read inside, one outsideSelection is allnew repos join by themselvesSelected, counts matchcomplete by coincidenceSelected, 12 of 140a clean report on 9 percentOrg total unreadablea count, not a coverage figure
Selected and complete is deliberately not the same verdict as all: it is correct today and nothing keeps it correct tomorrow.

How to fix it

Read the installation's own view first

GET /installation/repositories?per_page=100. Take repository_selection and total_count from the first page: total_count is the full size of the installation, while the repositories array is one page of it. If the selection is all, you are done and the answer is good news.

Get the organization's real total from outside the App

GET /orgs/{org} returns public_repos and, for callers with enough access, total_private_repos. Add them. Where total_private_repos is absent, do not substitute the public count and call it a total — report that the comparison could not be made, because a coverage number computed from half the denominator is a confident understatement of the gap.

Compare, and treat a match as fragile rather than fixed

Twelve of a hundred and forty is the obvious finding. A hundred and forty of a hundred and forty on a selected installation is the subtle one: complete today and complete by coincidence, because nothing adds the repository somebody creates this afternoon. Those two deserve different words in the report and both deserve a mention.

Name the repositories that are outside, not just the count

With a credential that can list GET /orgs/{org}/repos?per_page=100, diff the full names against the installation's list. A count starts an argument about whether the count is right; a list of twelve repository names that nobody has ever scanned ends it.

Make coverage part of every run, permanently

The repair is to switch the installation to All repositories, or to add the missing ones explicitly. The durable fix is that the tool asserts its own coverage at startup and prints it in the summary next to the findings, so "0 findings" is never again allowed to appear without the number of repositories that produced it.

How to check it worked

Re-run after widening the installation. The state should be all-repositories, and the count the script prints should match the organization's own total.

python3 github_app_coverage_audit.py --org acme
# all-repositories   140 repository(ies) visible; new repositories join automatically

The full code

Two GET requests: one inside the installation, one outside it. The pure functions are the denominator and the comparison, kept apart on purpose — deciding that an organization total is unreadable is a different judgement from deciding what a gap means, and folding them together is how a missing total_private_repos quietly becomes a coverage figure of 100%.

Get this script on GitHub Follow @allanninal Python and Node.js, with tests. Read only, it never writes. One of 24 GitHub API fixes, free and open source.
github_app_coverage_audit.py
"""Report how much of an organization a GitHub App installation can actually see.

Read only. Two GET requests and no writes: an installation token plus a token
that can read the organization is enough. The repair is printed, never performed.
"""
import argparse
import logging
import os
import sys

import requests

logging.basicConfig(level=logging.INFO, format="%(asctime)s %(levelname)s %(message)s")
log = logging.getLogger("github_app_coverage_audit")

API = "https://api.github.com"
UA = "github-app-coverage-audit/1.0"


def expected_total(org):
    """Repositories the organization actually has, or None if it cannot be known.

    public_repos plus total_private_repos. total_private_repos is only returned
    to callers with enough access; when it is absent the public count is a floor
    and not a total. Returning it anyway would produce a coverage figure that
    understates the gap, so this returns None and lets the caller say so.
    """
    if not isinstance(org, dict):
        return None
    public = org.get("public_repos")
    private = org.get("total_private_repos")
    if public is None or private is None:
        return None
    return int(public) + int(private)


def coverage(selection, seen, expected):
    """Compare what the installation sees against what exists. Pure.

    Returns (state, detail). A `selected` installation whose count happens to
    match today is deliberately not the same state as `all`: it is correct now
    and nothing keeps it correct.
    """
    sel = str(selection or "").strip().lower()

    if sel == "all":
        return ("all-repositories",
                "%d repository(ies) visible, and repository_selection is 'all', "
                "so repositories created later join the installation "
                "automatically." % (seen,))

    if sel != "selected":
        return ("unknown-selection",
                "repository_selection is %r, which is neither 'all' nor "
                "'selected'. Do not assume coverage from a value you cannot "
                "interpret." % (selection,))

    if expected is None:
        return ("unmeasured",
                "%d repository(ies) selected. The organization's own total is "
                "not readable with this credential, so this is a count and not a "
                "coverage figure. Say so in the report rather than implying "
                "completeness." % (seen,))

    if seen > expected:
        return ("inconsistent",
                "%d repository(ies) visible against an organization total of %d. "
                "The installation spans more than this organization, or one of "
                "the two counts is stale. Resolve it before quoting either."
                % (seen, expected))

    if seen == expected:
        return ("selected-complete",
                "%d of %d today, and nothing keeps it that way: a 'selected' "
                "installation does not pick up repositories created later, so "
                "this is complete by coincidence." % (seen, expected))

    return ("partial",
            "%d of %d repositories. Every endpoint answers truthfully about "
            "those %d and says nothing at all about the other %d, so a clean "
            "report here covers %.0f%% of the organization."
            % (seen, expected, seen, expected - seen, 100.0 * seen / expected))


def get(session, url, **params):
    return session.get(url, params=params, timeout=30)


def installation_view(session, api):
    """repository_selection, total_count and the full names, from inside the App."""
    names = []
    selection, total = None, 0
    page = 1
    while True:
        r = get(session, api + "/installation/repositories", per_page=100, page=page)
        if r.status_code != 200:
            raise SystemExit("%d from GET /installation/repositories: this needs "
                             "an App installation token" % (r.status_code,))
        body = r.json()
        if page == 1:
            selection = body.get("repository_selection")
            total = int(body.get("total_count") or 0)
        items = body.get("repositories", [])
        names.extend(str(r_.get("full_name") or "") for r_ in items)
        if len(items) < 100:
            break
        page += 1
    return selection, total, names


def org_repo_names(session, api, org):
    """Every repository in the organization, from outside the installation."""
    names = []
    page = 1
    while True:
        r = get(session, "%s/orgs/%s/repos" % (api, org), per_page=100, page=page)
        if r.status_code != 200:
            return None
        items = r.json()
        names.extend(str(x.get("full_name") or "") for x in items)
        if len(items) < 100:
            break
        page += 1
    return names


def main():
    ap = argparse.ArgumentParser(description=__doc__)
    ap.add_argument("--org", required=True,
                    help="the organization the installation is meant to cover")
    ap.add_argument("--api", default=API,
                    help="API host, for GitHub Enterprise Server")
    ap.add_argument("--list-missing", action="store_true",
                    help="name the repositories outside the installation")
    args = ap.parse_args()

    token = os.environ.get("GITHUB_TOKEN")
    if not token:
        log.error("set GITHUB_TOKEN (an App installation token, read-only)")
        return 2

    session = requests.Session()
    session.headers.update({
        "Authorization": "Bearer " + token,
        "Accept": "application/vnd.github+json",
        "X-GitHub-Api-Version": "2022-11-28",
        "User-Agent": UA,
    })

    selection, seen, inside = installation_view(session, args.api)

    org_response = get(session, "%s/orgs/%s" % (args.api, args.org))
    expected = expected_total(org_response.json()) if org_response.status_code == 200 else None

    state, detail = coverage(selection, seen, expected)
    line = "%-18s %s" % (state, detail)
    if state == "all-repositories":
        log.info(line)
        return 0

    log.warning(line)
    if args.list_missing:
        outside = org_repo_names(session, args.api, args.org)
        if outside is None:
            log.warning("  the organization's repository list is not readable "
                        "with this credential, so the missing names cannot be "
                        "printed. The counts above still stand.")
        else:
            have = {n.lower() for n in inside}
            missing = sorted(n for n in outside if n.lower() not in have)
            for name in missing[:50]:
                log.warning("  outside the installation: %s", name)
            if len(missing) > 50:
                log.warning("  ... and %d more", len(missing) - 50)

    log.warning("  repair: switch the installation to All repositories, or add "
                "the missing repositories to it. Then have the tool print its "
                "own coverage next to its findings, so a clean report can never "
                "again appear without the number of repositories behind it.")
    return 1


if __name__ == "__main__":
    sys.exit(main())
github-app-coverage-audit.mjs
/**
 * Report how much of an organization a GitHub App installation can actually see.
 *
 * Read only. Two GET requests and no writes. The repair is printed, never
 * performed.
 */
const API = 'https://api.github.com';
const UA = 'github-app-coverage-audit/1.0';

/**
 * Repositories the organization actually has, or null if it cannot be known.
 * total_private_repos is only returned to callers with enough access; without it
 * the public count is a floor, and a coverage figure built on a floor understates
 * the gap, so this returns null rather than a number.
 */
export function expectedTotal(org) {
  if (!org || typeof org !== 'object') return null;
  const pub = org.public_repos;
  const priv = org.total_private_repos;
  if (pub === null || pub === undefined) return null;
  if (priv === null || priv === undefined) return null;
  return Number(pub) + Number(priv);
}

/**
 * Compare what the installation sees against what exists. Pure.
 * Returns [state, detail].
 */
export function coverage(selection, seen, expected) {
  const sel = String(selection ?? '').trim().toLowerCase();

  if (sel === 'all') {
    return ['all-repositories',
      `${seen} repository(ies) visible, and repository_selection is 'all', so ` +
      'repositories created later join the installation automatically.'];
  }

  if (sel !== 'selected') {
    return ['unknown-selection',
      `repository_selection is ${JSON.stringify(selection)}, which is neither ` +
      "'all' nor 'selected'. Do not assume coverage from a value you cannot " +
      'interpret.'];
  }

  if (expected === null || expected === undefined) {
    return ['unmeasured',
      `${seen} repository(ies) selected. The organization's own total is not ` +
      'readable with this credential, so this is a count and not a coverage ' +
      'figure. Say so in the report rather than implying completeness.'];
  }

  if (seen > expected) {
    return ['inconsistent',
      `${seen} repository(ies) visible against an organization total of ` +
      `${expected}. The installation spans more than this organization, or one ` +
      'of the two counts is stale. Resolve it before quoting either.'];
  }

  if (seen === expected) {
    return ['selected-complete',
      `${seen} of ${expected} today, and nothing keeps it that way: a ` +
      "'selected' installation does not pick up repositories created later, so " +
      'this is complete by coincidence.'];
  }

  const pct = Math.round((100 * seen) / expected);
  return ['partial',
    `${seen} of ${expected} repositories. Every endpoint answers truthfully ` +
    `about those ${seen} and says nothing at all about the other ` +
    `${expected - seen}, so a clean report here covers ${pct}% of the ` +
    'organization.'];
}

function headers(token) {
  return {
    Authorization: `Bearer ${token}`,
    Accept: 'application/vnd.github+json',
    'X-GitHub-Api-Version': '2022-11-28',
    'User-Agent': UA,
  };
}

async function get(token, url, params = {}) {
  const u = new URL(url);
  for (const [k, v] of Object.entries(params)) u.searchParams.set(k, v);
  return fetch(u, { headers: headers(token) });
}

export async function installationView(token, api = API) {
  const names = [];
  let selection = null;
  let total = 0;
  let page = 1;
  for (;;) {
    const res = await get(token, `${api}/installation/repositories`,
                          { per_page: 100, page });
    if (res.status !== 200) {
      throw new Error(`${res.status} from GET /installation/repositories: this ` +
                      'needs an App installation token');
    }
    const body = await res.json();
    if (page === 1) {
      selection = body.repository_selection;
      total = Number(body.total_count ?? 0);
    }
    const items = body.repositories ?? [];
    names.push(...items.map((r) => String(r.full_name ?? '')));
    if (items.length < 100) break;
    page += 1;
  }
  return { selection, total, names };
}

async function main() {
  const token = process.env.GITHUB_TOKEN;
  if (!token) {
    console.error('set GITHUB_TOKEN (an App installation token, read-only)');
    process.exitCode = 2;
    return;
  }
  const at = process.argv.indexOf('--org');
  const org = at >= 0 ? process.argv[at + 1] : null;
  if (!org) {
    console.error('pass --org <login>');
    process.exitCode = 2;
    return;
  }

  const { selection, total: seen } = await installationView(token);

  const orgRes = await get(token, `${API}/orgs/${org}`);
  const expected = orgRes.status === 200 ? expectedTotal(await orgRes.json()) : null;

  const [state, detail] = coverage(selection, seen, expected);
  const line = `${state.padEnd(18)} ${detail}`;
  if (state === 'all-repositories') {
    console.log(line);
    return;
  }

  console.warn(line);
  console.warn('  repair: switch the installation to All repositories, or add the ' +
               'missing repositories to it. Then have the tool print its own ' +
               'coverage next to its findings, so a clean report can never again ' +
               'appear without the number of repositories behind it.');
  process.exitCode = 1;
}

// Only run when invoked directly. The test file imports this module, and without
// the guard main() would run there too, fail on the missing token, and set a
// non-zero exit code that fails the whole test file even as every test passes.
if (import.meta.url === `file://${process.argv[1]}`) {
  main().catch((err) => { console.error(err.message); process.exitCode = 2; });
}

Add a test

Two cases are worth pinning. A selected installation whose count matches the organization today must not report as all, because the two differ entirely in what happens next week. And an organization object with no total_private_repos must produce no coverage figure at all — the tempting shortcut is to fall back to public_repos, which turns an unmeasurable gap into a reassuring percentage.

test_github_app_coverage_audit.py
from github_app_coverage_audit import coverage, expected_total


def test_org_total_needs_both_halves():
    assert expected_total({"public_repos": 40, "total_private_repos": 100}) == 140
    assert expected_total({"public_repos": 0, "total_private_repos": 0}) == 0


def test_a_missing_private_count_yields_no_total_at_all():
    # Falling back to public_repos here is how an unmeasurable gap becomes a
    # reassuring percentage.
    assert expected_total({"public_repos": 40}) is None
    assert expected_total({}) is None
    assert expected_total(None) is None


def test_all_repositories_is_the_only_good_news():
    state, detail = coverage("all", 140, 140)
    assert state == "all-repositories"
    assert "automatically" in detail


def test_twelve_of_a_hundred_and_forty_names_the_gap_and_the_share():
    state, detail = coverage("selected", 12, 140)
    assert state == "partial"
    assert "12 of 140" in detail
    assert "128" in detail
    assert "9%" in detail


def test_selected_and_complete_is_not_the_same_as_all():
    # Correct today, and nothing keeps it correct.
    state, detail = coverage("selected", 140, 140)
    assert state == "selected-complete"
    assert "coincidence" in detail


def test_no_org_total_means_a_count_not_a_coverage_figure():
    state, detail = coverage("selected", 12, None)
    assert state == "unmeasured"
    assert "not a coverage figure" in detail


def test_seeing_more_than_exists_is_reported_rather_than_averaged_away():
    state, _ = coverage("selected", 150, 140)
    assert state == "inconsistent"


def test_an_uninterpretable_selection_is_never_assumed_complete():
    assert coverage(None, 12, 140)[0] == "unknown-selection"
    assert coverage("some-new-value", 12, 140)[0] == "unknown-selection"
github-app-coverage-audit.test.mjs
import { test } from 'node:test';
import assert from 'node:assert/strict';
import { coverage, expectedTotal } from './github-app-coverage-audit.mjs';

test('org total needs both halves', () => {
  assert.equal(expectedTotal({ public_repos: 40, total_private_repos: 100 }), 140);
  assert.equal(expectedTotal({ public_repos: 0, total_private_repos: 0 }), 0);
});

test('a missing private count yields no total at all', () => {
  assert.equal(expectedTotal({ public_repos: 40 }), null);
  assert.equal(expectedTotal({}), null);
  assert.equal(expectedTotal(null), null);
});

test('all repositories is the only good news', () => {
  const [state, detail] = coverage('all', 140, 140);
  assert.equal(state, 'all-repositories');
  assert.match(detail, /automatically/);
});

test('twelve of a hundred and forty names the gap and the share', () => {
  const [state, detail] = coverage('selected', 12, 140);
  assert.equal(state, 'partial');
  assert.match(detail, /12 of 140/);
  assert.match(detail, /128/);
  assert.match(detail, /9%/);
});

test('selected and complete is not the same as all', () => {
  const [state, detail] = coverage('selected', 140, 140);
  assert.equal(state, 'selected-complete');
  assert.match(detail, /coincidence/);
});

test('no org total means a count, not a coverage figure', () => {
  const [state, detail] = coverage('selected', 12, null);
  assert.equal(state, 'unmeasured');
  assert.match(detail, /not a coverage figure/);
});

test('seeing more than exists is reported rather than averaged away', () => {
  assert.equal(coverage('selected', 150, 140)[0], 'inconsistent');
});

test('an uninterpretable selection is never assumed complete', () => {
  assert.equal(coverage(null, 12, 140)[0], 'unknown-selection');
  assert.equal(coverage('some-new-value', 12, 140)[0], 'unknown-selection');
});

FAQ

How do I find out whether an installation covers every repository?

GET /installation/repositories returns repository_selection alongside total_count. A value of all means the installation follows the account and picks up new repositories; selected means a fixed list. Only the first of those can be assumed complete.

Why does the App not see repositories created after it was installed?

Because a selected installation is a list, not a rule. Repositories are added to it by a person, so anything created afterwards is outside it until somebody goes back and ticks it. This is the reason the gap only ever grows.

Is there a flag on the response that says the results are incomplete?

No, and that is the whole difficulty. Every endpoint under the installation token returns a correct, complete answer for the installation's scope. There is no truncation marker to check, so the incompleteness has to be established by comparing against a count obtained from outside the App.

What if I cannot read the organization's total?

total_private_repos on GET /orgs/{org} is only returned to callers with enough access. Without it, report the number of repositories the installation covers and state plainly that coverage could not be computed. Substituting public_repos produces a percentage that is confidently too high.

The counts match. Is the installation fine?

Today. A selected installation that happens to cover everything right now still does not cover the repository somebody creates this afternoon, so it is worth reporting as its own state rather than as a pass. Switching to All repositories is what actually removes the failure mode.

Related field notes

Sources

Every figure in this note is traced to one of these. Prices are list rates and change — check them for your own region before acting.

Stuck on a tricky one?

If your setup is misbehaving in a way this note does not cover, message me on LinkedIn with what you are seeing.
