the receiver still checks the legacy SHA-1 signature
The receiver verifies. It reads a signature header, computes an HMAC over the raw body, compares in constant time and returns 401 when they differ. It has been doing that since 2017, which is the problem: the header it reads is X-Hub-Signature, the SHA-1 one GitHub keeps sending for the sake of receivers exactly like this one.
GitHub sends two signature headers on every delivery from a hook that has a secret: X-Hub-Signature, an HMAC-SHA1 kept for backwards compatibility, and X-Hub-Signature-256, the HMAC-SHA256 one you should be verifying. Both are present, both are computed from the same secret, and a receiver that checks only the first passes every test it has.
This is a receiver-side choice, so no API read can see it. What the API can do is establish that signatures are being sent at all — config.secret masked as ******** on GET /repos/{owner}/{repo}/hooks, and both header names listed under request.headers on a delivery — and then the script reads your receiver's source from disk and reports which header name appears in it. The trap there is that the modern name contains the legacy name as a prefix, so a naive substring search reports every correct receiver as a legacy one.
The problem in plain words
Nothing fails, which is the entire difficulty. A SHA-1 signature check rejects forged payloads and accepts genuine ones, so the integration behaves correctly on every input anybody has ever sent it. There is no error log, no failed delivery, no alert. The only way to discover it is to go and look at a line of code that has not been touched in years and has no reason to draw attention to itself, because it is in the part of the receiver that works.
The search is also easy to do badly. Somebody greps the repository for X-Hub-Signature, finds a hit, and concludes the receiver is legacy — except the hit is inside X-Hub-Signature-256, because one string is a prefix of the other. The same mistake runs the other way in code: a header lookup written as a startswith or a loose match will happily read the modern header into a routine that then verifies it as SHA-1 and fails every time, which at least announces itself. The silent version is the one that greps clean and is wrong.
And the framing gets confused with a different problem. A hook with no secret sends no signature header at all, so a receiver written to verify if the header is present verifies nothing; that is a different note with a different finding. Here the secret exists, the headers arrive, the verification runs, and the digest is a weaker one than the one sitting in the next header along.
Why it happens
Both headers are always sent when a secret is set. GitHub did not replace the SHA-1 header, it added the SHA-256 one alongside it, precisely so that receivers written before the change kept working. That is a kindness with a cost: nothing about a legacy receiver is broken, so nothing about it gets noticed.
The API's blind spot here is total and worth stating. GitHub knows what it sent. It has no idea what you checked. Every entry in a delivery record describes the request GitHub made and the response your server gave, and there is no field anywhere that reports which header your code read. Any tool that claims to detect this from the API alone is guessing.
So the evidence has to come from your own source, and that is a proxy too. A grep for a header name finds the ordinary case, where the name is a literal in the code. It cannot see a header name built at runtime, read from configuration, or hidden behind a framework helper, and it cannot tell a live verification from a commented-out one. The script reports what it found and says plainly what it cannot see, rather than converting a text search into a verdict it has not earned.
Accepting either header is not half a fix. A receiver that tries SHA-256 and falls back to SHA-1 accepts a SHA-1 signature from anyone who can produce one, which is exactly the population that could produce one before. The weaker check is the one that decides. Support for both is a migration state, not a destination, and the script reports it as a finding rather than as a pass.
Nothing in the repair touches GitHub. This is the one webhook problem in this batch that is fixed entirely in your code: read X-Hub-Signature-256, compute the HMAC over the exact raw request bytes, compare with a constant-time comparison, reject when the header is missing, and delete the SHA-1 branch. The hook config is already correct, which is why no amount of staring at it helps.
The fix, as a flow
The API half of this script proves only that signatures are being sent. Which header the receiver verifies is a decision in your own source, and GitHub records what it sent rather than what you checked, so a tool that stops at the API can print a recommendation and never a finding. The second half reads files. It reports line numbers and never lines, and it is built around the one detail that makes a naive search worse than none: the legacy header name is a prefix of the modern one, so a plain substring match flags every correct receiver on exactly the lines where it is right.
How to fix it
Confirm a signature is being sent at all
GET /repos/{owner}/{repo}/hooks and read config. A secret that is set comes back masked as ********; when there is no secret the key is absent entirely and GitHub sends neither header, which is a different problem with a different note. This step is what makes the rest of the check meaningful.
Read one delivery's request headers
GET /repos/{owner}/{repo}/hooks/{hook_id}/deliveries for a recent id, then the single-delivery endpoint for the detail. request.headers lists what GitHub actually sent, including both signature header names. This is evidence, not diagnosis: it proves the modern header was available to your receiver.
Search your receiver, with the prefix trap in mind
Normalise each line, remove every occurrence of the modern name first, and only then look for the legacy one in what is left. Doing it in the other order, or with a plain substring test, reports a correct receiver as a legacy one on every single line where it gets it right.
Report line numbers, never lines
The script prints the file and the line number and which header name was found there. It does not print the line, because source that handles signatures is exactly the source most likely to have a secret sitting on the line above, and a diagnostic tool that pastes your code into a terminal or a CI log is a poor trade for the convenience.
Move the check, then remove the fallback
Switch the comparison to X-Hub-Signature-256 and the digest to SHA-256 over the raw bytes. Then delete the SHA-1 path rather than keeping it as a fallback: a receiver that accepts either is exactly as strong as the weaker of the two. Reject a request whose header is missing instead of skipping the check.
How to check it worked
After the change the scan finds the modern name and nothing else, and the receiver returns 401 for a request with no signature header rather than accepting it.
GITHUB_TOKEN=$GH_READONLY python3 github_hook_signature_headers.py \
--repo acme-corp/api --receiver ../receiver/src
# hook 512334455: secret is set, GitHub sent both signature headers
# source scan: 2 reference(s) across 1 file(s)
# receiver/src/hooks.py:41 legacy X-Hub-Signature
# receiver/src/hooks.py:44 legacy X-Hub-Signature
# sha1-only: the receiver names only the legacy SHA-1 header. GitHub sent the
# SHA-256 header on the same request and it is being ignored.
# repair: verify X-Hub-Signature-256 over the raw request bytes with a
# constant-time comparison, then delete the SHA-1 branch.
# after the change
# sha256-only: the receiver names only X-Hub-Signature-256
The full code
Two GETs establish that signatures are being sent, and then the script does something the other notes in this section do not: it reads files. That is the only honest way to answer this one, because the decision it is about lives in your source and nothing at GitHub records it. The pure core is a header-name scanner built around the fact that the legacy name is a prefix of the modern one, a normaliser for the underscore and case variants that different runtimes hand you, a reporter that emits line numbers and never line contents, and a verdict that treats accepting both headers as a finding rather than as a pass.
"""Report which webhook signature header your receiver actually verifies.
Read only in both senses. Every API call is a GET, and the local source scan
opens files for reading and prints line numbers rather than lines.
GitHub sends two signature headers on every delivery from a hook that has a
secret set:
X-Hub-Signature HMAC-SHA1, kept for backwards compatibility
X-Hub-Signature-256 HMAC-SHA256, the one to verify
Which of them your receiver checks is a decision in your own code. No API read
can see it, so this script establishes from the API that both headers were
sent, then searches your receiver's source for the header names and reports
what it found. That is a proxy and it is described as one: a header name built
at runtime, read from configuration or hidden inside a framework helper is
invisible to a text search.
The one subtlety worth the code: "x-hub-signature" is a prefix of
"x-hub-signature-256", so a plain substring search reports every correct
receiver as a legacy one. The modern name is removed from each line before the
legacy name is looked for.
The secret is never printed. config.secret comes back masked and this script
reports its presence only.
Environment:
GITHUB_TOKEN a read-only token that can see the repository's hooks
"""
import argparse
import json
import logging
import os
import sys
import requests
logging.basicConfig(level=logging.INFO, format="%(asctime)s %(levelname)s %(message)s")
log = logging.getLogger("github_hook_signature_headers")
API = "https://api.github.com"
UA = "github-hook-signature-headers/1.0"
MODERN = "x-hub-signature-256"
LEGACY = "x-hub-signature"
# Source files worth opening. Everything else in a repository is noise, and a
# scan that opens every file is a scan that reads secrets out of .env by
# accident.
SUFFIXES = (".py", ".js", ".mjs", ".cjs", ".ts", ".tsx", ".rb", ".go", ".php",
".java", ".kt", ".cs", ".rs", ".ex", ".exs")
# States that mean the reader has something to change.
FINDINGS = ("sha1-only", "both-accepted", "no-verification-found")
def normalized(text):
"""Lower-cased, with underscores folded to hyphens. Pure.
The same header reaches code as X-Hub-Signature-256, x-hub-signature-256
and HTTP_X_HUB_SIGNATURE_256 depending on the runtime, and all three should
count as the same reference.
"""
return str(text or "").lower().replace("_", "-")
def secret_state(hook):
"""Whether the hook has a secret set: set, absent or unknown. Pure.
The value is masked by GitHub and is never returned by this function. A set
secret is a key present in config; an unset one is a key that is not there
at all, which is a different note.
"""
if not isinstance(hook, dict):
return "unknown"
config = hook.get("config")
if not isinstance(config, dict):
return "unknown"
return "set" if "secret" in config else "absent"
def redacted_config(config):
"""A copy of a hook config safe to print. Pure.
The secret arrives masked, so printing it would leak nothing today. It is
replaced anyway, because the guarantee this section makes is about what the
script can emit rather than about what GitHub happens to send.
"""
if not isinstance(config, dict):
return {}
out = dict(config)
if "secret" in out:
out["secret"] = "<set>"
return out
def header_names(headers):
"""Normalised header names from a delivery record. Pure. Values discarded.
request.headers is an object, but the same data reaches this function as a
list of name/value pairs or as raw header lines depending on what stored
it, so all three shapes are accepted and only the names survive.
"""
names = []
if isinstance(headers, dict):
names = list(headers.keys())
elif isinstance(headers, list):
for row in headers:
if isinstance(row, dict) and row.get("name"):
names.append(row["name"])
elif isinstance(row, str) and ":" in row:
names.append(row.split(":", 1)[0])
elif isinstance(row, str):
names.append(row)
return [normalized(n).strip() for n in names]
def signature_headers(headers):
"""Which signature headers GitHub sent on a delivery. Pure.
Exact name matching, so the prefix problem does not arise here; it arises
in the source scan below, where the names appear inside other text.
"""
names = header_names(headers)
return {"sha256": MODERN in names, "sha1": LEGACY in names}
def scan_line(line):
"""Which signature header names a single line refers to. Pure.
The modern name is removed first. Looking for the legacy name in the raw
line instead finds a hit inside every correct reference, which turns a
passing receiver into a finding on every line where it is right.
"""
norm = normalized(line)
kinds = []
if MODERN in norm:
kinds.append("sha256")
norm = norm.replace(MODERN, " ")
if LEGACY in norm:
kinds.append("sha1")
return kinds
def scan_source(text, path="<source>"):
"""Every signature header reference in a file, as (path, line, kind). Pure.
Line numbers only. The contents of a line that handles signatures are the
contents most likely to sit next to a secret, and a diagnostic that pastes
them into a terminal or a CI log has made the problem worse.
"""
hits = []
for number, line in enumerate(str(text or "").splitlines(), start=1):
for kind in scan_line(line):
hits.append((path, number, kind))
return hits
def receiver_state(hits):
"""What the scan says the receiver names. Pure.
none means the header names do not appear in the source that was scanned,
which is not the same as "does not verify" and is not reported as if it
were.
"""
kinds = {kind for _, _, kind in hits or []}
if not kinds:
return "none"
if kinds == {"sha256"}:
return "sha256-only"
if kinds == {"sha1"}:
return "sha1-only"
return "both"
def format_hit(hit):
"""One line of the scan report. Pure. Never includes source text."""
path, number, kind = hit
name = "X-Hub-Signature-256" if kind == "sha256" else "X-Hub-Signature"
label = "modern" if kind == "sha256" else "legacy"
return "%s:%d %s %s" % (path, number, label, name)
def verdict(secret, sig=None, receiver=None):
"""Combine the API evidence and the source scan into a finding. Pure.
secret is the output of secret_state, sig the output of signature_headers
or None when no delivery was read, receiver the output of receiver_state or
None when no source was scanned.
"""
if secret == "absent":
return ("no-secret",
"this hook has no secret, so GitHub sends neither signature "
"header and there is nothing for the receiver to verify. That "
"is a different and larger problem than which digest you use.")
if sig is not None and not sig.get("sha256") and not sig.get("sha1"):
return ("headers-missing",
"the delivery that was read carries no signature header at "
"all. Either it predates the secret being set, or the record "
"is not a delivery from this hook.")
if receiver is None:
return ("not-scanned",
"GitHub sent the SHA-256 header. Which header the receiver "
"verifies is not visible from the API, so point the scan at "
"the receiver's source to get an answer rather than a "
"recommendation.")
if receiver == "none":
return ("no-verification-found",
"neither signature header name appears in the source that was "
"scanned. Either the receiver does not verify, or it builds "
"the header name at runtime, or the verification lives "
"somewhere the scan was not pointed at.")
if receiver == "sha1-only":
return ("sha1-only",
"the receiver names only the legacy SHA-1 header. GitHub sent "
"the SHA-256 header on the same request and it is being "
"ignored.")
if receiver == "both":
return ("both-accepted",
"the receiver names both headers. A receiver that accepts "
"either is exactly as strong as the weaker one, so this is a "
"migration state rather than a finished one.")
return ("sha256-only",
"the receiver names only X-Hub-Signature-256, which is the header "
"to verify.")
def repair(state):
"""The change to make, in the reader's own code. Pure."""
if state == "no-secret":
return ("set a secret on the hook first. Until there is one, GitHub "
"sends no signature and no digest choice matters.")
if state == "headers-missing":
return ("read a delivery from after the secret was set, then re-run.")
if state == "not-scanned":
return ("re-run with --receiver pointed at the source tree that "
"handles the webhook.")
if state == "no-verification-found":
return ("confirm by hand that the receiver verifies at all. If it does "
"not, verify X-Hub-Signature-256 over the raw request bytes "
"with a constant-time comparison and reject a request whose "
"header is missing.")
if state in ("sha1-only", "both-accepted"):
return ("verify X-Hub-Signature-256 over the raw request bytes with a "
"constant-time comparison, then delete the SHA-1 branch rather "
"than keeping it as a fallback.")
return "nothing. This receiver verifies the header GitHub wants it to."
def scan_paths(paths, suffixes=SUFFIXES, max_bytes=2_000_000):
"""Walk files and directories, scanning source for header references.
Read only: files are opened for reading and only line numbers leave this
function.
"""
hits = []
scanned = []
for root in paths or []:
for path in _walk(root, suffixes):
try:
if os.path.getsize(path) > max_bytes:
continue
with open(path, "r", encoding="utf-8", errors="replace") as fh:
text = fh.read()
except OSError as exc:
log.warning("could not read %s: %s", path, exc)
continue
scanned.append(path)
hits.extend(scan_source(text, path))
return hits, scanned
def _walk(root, suffixes):
"""Every candidate source file under a path."""
if os.path.isfile(root):
return [root]
out = []
for base, dirs, files in os.walk(root):
dirs[:] = [d for d in dirs if d not in
(".git", "node_modules", "venv", ".venv", "__pycache__", "dist", "build")]
for name in files:
if name.endswith(suffixes):
out.append(os.path.join(base, name))
return out
def get(session, path):
"""One GET. Returns (status, json-or-None)."""
url = API + path if path.startswith("/") else path
r = session.get(url, timeout=30)
try:
body = r.json()
except ValueError:
body = None
return r.status_code, body
def latest_delivery_headers(session, repo, hook_id):
"""The request headers of the most recent delivery, or None. Read only."""
status, rows = get(session, "/repos/%s/hooks/%s/deliveries?per_page=10"
% (repo, hook_id))
if status != 200 or not isinstance(rows, list) or not rows:
return None
for row in rows:
if not isinstance(row, dict) or not row.get("id"):
continue
status, body = get(session, "/repos/%s/hooks/%s/deliveries/%s"
% (repo, hook_id, row["id"]))
if status == 200 and isinstance(body, dict):
request = body.get("request")
if isinstance(request, dict):
return request.get("headers")
return None
def main():
ap = argparse.ArgumentParser(description=__doc__)
ap.add_argument("--repo", required=True, help="owner/name")
ap.add_argument("--hook-id", help="one hook; omit to check every hook")
ap.add_argument("--receiver", action="append", default=[],
help="file or directory to scan for header names; repeatable")
args = ap.parse_args()
token = os.environ.get("GITHUB_TOKEN")
if not token:
log.error("set GITHUB_TOKEN to a read-only token that can see the "
"repository's hooks")
return 2
session = requests.Session()
session.headers.update({
"Authorization": "Bearer " + token,
"Accept": "application/vnd.github+json",
"X-GitHub-Api-Version": "2022-11-28",
"User-Agent": UA,
})
status, hooks = get(session, "/repos/%s/hooks?per_page=100" % args.repo)
if status != 200 or not isinstance(hooks, list):
log.error("GET /repos/%s/hooks returned %d", args.repo, status)
return 2
if args.hook_id:
hooks = [h for h in hooks if str(h.get("id")) == str(args.hook_id)]
hits, scanned = scan_paths(args.receiver)
state_of_receiver = receiver_state(hits) if args.receiver else None
if args.receiver:
log.info("source scan: %d reference(s) across %d file(s)",
len(hits), len(set(p for p, _, _ in hits)))
for hit in hits:
log.info(" %s", format_hit(hit))
findings = []
for hook in hooks:
secret = secret_state(hook)
headers = None
if secret == "set":
headers = latest_delivery_headers(session, args.repo, hook.get("id"))
sig = signature_headers(headers) if headers is not None else None
state, detail = verdict(secret, sig, state_of_receiver)
log.info("hook %s: secret is %s, %s", hook.get("id"), secret,
"GitHub sent both signature headers"
if sig and sig["sha1"] and sig["sha256"]
else "no delivery headers were read")
log.info("%s: %s", state, detail)
log.info("repair: %s", repair(state))
findings.append({"hook_id": hook.get("id"), "secret": secret,
"signature_headers": sig, "state": state,
"detail": detail,
"config": redacted_config(hook.get("config"))})
print(json.dumps({"repo": args.repo, "files_scanned": len(scanned),
"references": [format_hit(h) for h in hits],
"findings": findings}, indent=2, default=str))
return 1 if any(f["state"] in FINDINGS for f in findings) else 0
if __name__ == "__main__":
sys.exit(main())
/**
* Report which webhook signature header your receiver actually verifies.
*
* Read only in both senses: every API call is a GET, and the local source scan
* opens files for reading and prints line numbers rather than lines.
*
* GitHub sends X-Hub-Signature (HMAC-SHA1, legacy) and X-Hub-Signature-256
* (HMAC-SHA256) on every delivery from a hook that has a secret. Which one the
* receiver checks lives in your source and no API read can see it, so the API
* half of this script only establishes that both were sent.
*
* The secret is never printed; its presence is reported and nothing else.
*
* Environment:
* GITHUB_TOKEN a read-only token that can see the repository's hooks
*
* Usage:
* node github-hook-signature-headers.mjs acme-corp/api ../receiver/src
*/
import { readFile, readdir, stat } from 'node:fs/promises';
import path from 'node:path';
const API = 'https://api.github.com';
const UA = 'github-hook-signature-headers/1.0';
export const MODERN = 'x-hub-signature-256';
export const LEGACY = 'x-hub-signature';
const SUFFIXES = ['.py', '.js', '.mjs', '.cjs', '.ts', '.tsx', '.rb', '.go',
'.php', '.java', '.kt', '.cs', '.rs', '.ex', '.exs'];
const SKIP_DIRS = ['.git', 'node_modules', 'venv', '.venv', '__pycache__',
'dist', 'build'];
/** States that mean the reader has something to change. */
export const FINDINGS = ['sha1-only', 'both-accepted', 'no-verification-found'];
/** Lower-cased, with underscores folded to hyphens. Pure. */
export function normalized(text) {
return String(text ?? '').toLowerCase().replaceAll('_', '-');
}
/** Whether the hook has a secret set: set, absent or unknown. Pure. */
export function secretState(hook) {
if (!hook || typeof hook !== 'object') return 'unknown';
const config = hook.config;
if (!config || typeof config !== 'object') return 'unknown';
return 'secret' in config ? 'set' : 'absent';
}
/** A copy of a hook config safe to print. Pure. */
export function redactedConfig(config) {
if (!config || typeof config !== 'object') return {};
const out = { ...config };
if ('secret' in out) out.secret = '<set>';
return out;
}
/** Normalised header names from a delivery record. Pure. Values discarded. */
export function headerNames(headers) {
let names = [];
if (Array.isArray(headers)) {
for (const row of headers) {
if (row && typeof row === 'object' && row.name) names.push(row.name);
else if (typeof row === 'string') names.push(row.includes(':') ? row.split(':')[0] : row);
}
} else if (headers && typeof headers === 'object') {
names = Object.keys(headers);
}
return names.map((n) => normalized(n).trim());
}
/** Which signature headers GitHub sent on a delivery. Pure. */
export function signatureHeaders(headers) {
const names = headerNames(headers);
return { sha256: names.includes(MODERN), sha1: names.includes(LEGACY) };
}
/**
* Which signature header names a single line refers to. Pure.
* The modern name is removed first, because the legacy name is a prefix of it.
*/
export function scanLine(line) {
let norm = normalized(line);
const kinds = [];
if (norm.includes(MODERN)) {
kinds.push('sha256');
norm = norm.replaceAll(MODERN, ' ');
}
if (norm.includes(LEGACY)) kinds.push('sha1');
return kinds;
}
/** Every signature header reference in a file, as [path, line, kind]. Pure. */
export function scanSource(text, filePath = '<source>') {
const hits = [];
const lines = String(text ?? '').split('\n');
for (let i = 0; i < lines.length; i += 1) {
for (const kind of scanLine(lines[i])) hits.push([filePath, i + 1, kind]);
}
return hits;
}
/** What the scan says the receiver names. Pure. */
export function receiverState(hits) {
const kinds = new Set((hits ?? []).map(([, , kind]) => kind));
if (kinds.size === 0) return 'none';
if (kinds.size === 1 && kinds.has('sha256')) return 'sha256-only';
if (kinds.size === 1 && kinds.has('sha1')) return 'sha1-only';
return 'both';
}
/** One line of the scan report. Pure. Never includes source text. */
export function formatHit(hit) {
const [filePath, number, kind] = hit;
const name = kind === 'sha256' ? 'X-Hub-Signature-256' : 'X-Hub-Signature';
const label = kind === 'sha256' ? 'modern' : 'legacy';
return `${filePath}:${number} ${label} ${name}`;
}
/** Combine the API evidence and the source scan into a finding. Pure. */
export function verdict(secret, sig = null, receiver = null) {
if (secret === 'absent') {
return ['no-secret',
'this hook has no secret, so GitHub sends neither signature header and ' +
'there is nothing for the receiver to verify. That is a different and ' +
'larger problem than which digest you use.'];
}
if (sig !== null && !sig.sha256 && !sig.sha1) {
return ['headers-missing',
'the delivery that was read carries no signature header at all. Either ' +
'it predates the secret being set, or the record is not a delivery from ' +
'this hook.'];
}
if (receiver === null) {
return ['not-scanned',
'GitHub sent the SHA-256 header. Which header the receiver verifies is ' +
'not visible from the API, so point the scan at the receiver\'s source ' +
'to get an answer rather than a recommendation.'];
}
if (receiver === 'none') {
return ['no-verification-found',
'neither signature header name appears in the source that was scanned. ' +
'Either the receiver does not verify, or it builds the header name at ' +
'runtime, or the verification lives somewhere the scan was not pointed at.'];
}
if (receiver === 'sha1-only') {
return ['sha1-only',
'the receiver names only the legacy SHA-1 header. GitHub sent the ' +
'SHA-256 header on the same request and it is being ignored.'];
}
if (receiver === 'both') {
return ['both-accepted',
'the receiver names both headers. A receiver that accepts either is ' +
'exactly as strong as the weaker one, so this is a migration state ' +
'rather than a finished one.'];
}
return ['sha256-only',
'the receiver names only X-Hub-Signature-256, which is the header to verify.'];
}
/** The change to make, in the reader's own code. Pure. */
export function repair(state) {
if (state === 'no-secret') {
return 'set a secret on the hook first. Until there is one, GitHub sends ' +
'no signature and no digest choice matters.';
}
if (state === 'headers-missing') {
return 'read a delivery from after the secret was set, then re-run.';
}
if (state === 'not-scanned') {
return 're-run with a path to the source tree that handles the webhook.';
}
if (state === 'no-verification-found') {
return 'confirm by hand that the receiver verifies at all. If it does ' +
'not, verify X-Hub-Signature-256 over the raw request bytes with a ' +
'constant-time comparison and reject a request whose header is missing.';
}
if (state === 'sha1-only' || state === 'both-accepted') {
return 'verify X-Hub-Signature-256 over the raw request bytes with a ' +
'constant-time comparison, then delete the SHA-1 branch rather than ' +
'keeping it as a fallback.';
}
return 'nothing. This receiver verifies the header GitHub wants it to.';
}
async function walk(root) {
const info = await stat(root).catch(() => null);
if (!info) return [];
if (info.isFile()) return [root];
const out = [];
const entries = await readdir(root, { withFileTypes: true }).catch(() => []);
for (const entry of entries) {
if (entry.isDirectory()) {
if (SKIP_DIRS.includes(entry.name)) continue;
out.push(...await walk(path.join(root, entry.name)));
} else if (SUFFIXES.some((s) => entry.name.endsWith(s))) {
out.push(path.join(root, entry.name));
}
}
return out;
}
async function scanPaths(paths) {
const hits = [];
const scanned = [];
for (const root of paths ?? []) {
for (const file of await walk(root)) {
const text = await readFile(file, 'utf8').catch(() => null);
if (text === null) continue;
scanned.push(file);
hits.push(...scanSource(text, file));
}
}
return { hits, scanned };
}
async function get(token, endpoint) {
const res = await fetch(endpoint.startsWith('/') ? API + endpoint : endpoint, {
headers: {
Authorization: `Bearer ${token}`,
Accept: 'application/vnd.github+json',
'X-GitHub-Api-Version': '2022-11-28',
'User-Agent': UA,
},
});
let body = null;
try { body = await res.json(); } catch { body = null; }
return { status: res.status, body };
}
async function latestDeliveryHeaders(token, repo, hookId) {
const list = await get(token, `/repos/${repo}/hooks/${hookId}/deliveries?per_page=10`);
if (list.status !== 200 || !Array.isArray(list.body)) return null;
for (const row of list.body) {
if (!row || typeof row !== 'object' || !row.id) continue;
const one = await get(token, `/repos/${repo}/hooks/${hookId}/deliveries/${row.id}`);
if (one.status === 200 && one.body && typeof one.body === 'object') {
const request = one.body.request;
if (request && typeof request === 'object') return request.headers;
}
}
return null;
}
async function main() {
const token = process.env.GITHUB_TOKEN;
if (!token) {
console.error('set GITHUB_TOKEN to a read-only token that can see the ' +
"repository's hooks");
process.exitCode = 2;
return;
}
const [repo, ...receivers] = process.argv.slice(2);
if (!repo) {
console.error('usage: node github-hook-signature-headers.mjs owner/name [receiver-path...]');
process.exitCode = 2;
return;
}
const { status, body: hooks } = await get(token, `/repos/${repo}/hooks?per_page=100`);
if (status !== 200 || !Array.isArray(hooks)) {
console.error(`GET /repos/${repo}/hooks returned ${status}`);
process.exitCode = 2;
return;
}
const { hits, scanned } = await scanPaths(receivers);
const stateOfReceiver = receivers.length ? receiverState(hits) : null;
if (receivers.length) {
const files = new Set(hits.map(([f]) => f));
console.log(`source scan: ${hits.length} reference(s) across ${files.size} file(s)`);
for (const hit of hits) console.log(` ${formatHit(hit)}`);
}
const findings = [];
for (const hook of hooks) {
const secret = secretState(hook);
const headers = secret === 'set'
? await latestDeliveryHeaders(token, repo, hook.id)
: null;
const sig = headers !== null && headers !== undefined ? signatureHeaders(headers) : null;
const [state, detail] = verdict(secret, sig, stateOfReceiver);
console.log(`hook ${hook.id}: secret is ${secret}, ` +
(sig && sig.sha1 && sig.sha256
? 'GitHub sent both signature headers'
: 'no delivery headers were read'));
console.log(`${state}: ${detail}`);
console.log(`repair: ${repair(state)}`);
findings.push({
hook_id: hook.id,
secret,
signature_headers: sig,
state,
detail,
config: redactedConfig(hook.config),
});
}
console.log(JSON.stringify({
repo,
files_scanned: scanned.length,
references: hits.map(formatHit),
findings,
}, null, 2));
process.exitCode = findings.some((f) => FINDINGS.includes(f.state)) ? 1 : 0;
}
// Only run when invoked directly, so importing this module from the test file
// does not execute main() and set an exit code that fails the suite even as
// every test passes.
if (import.meta.url === `file://${process.argv[1]}`) {
main().catch((err) => { console.error(err.message); process.exitCode = 2; });
}
Add a test
One test matters more than the rest: a line that names only X-Hub-Signature-256 must produce a modern reference and no legacy one. Get that wrong and the tool reports every correct receiver as a legacy one, on every line where it is right. The others pin the runtime spellings of the same header, the guarantee that the scan emits line numbers and never line contents, the difference between a receiver that names both headers and one that names the right one, and the two states this note refuses to claim — a hook with no secret, and a source tree where nothing was found.
from github_hook_signature_headers import (
format_hit, header_names, normalized, receiver_state, redacted_config,
repair, scan_line, scan_source, secret_state, signature_headers, verdict,
)
MODERN_LINE = 'sig = request.headers["X-Hub-Signature-256"]'
LEGACY_LINE = 'sig = request.headers["X-Hub-Signature"]'
WSGI_LINE = 'sig = environ["HTTP_X_HUB_SIGNATURE_256"]'
SECRET_SET = {"id": 1, "config": {"url": "https://example.com/hook",
"secret": "********", "content_type": "json"}}
NO_SECRET = {"id": 2, "config": {"url": "https://example.com/hook",
"content_type": "json"}}
def test_the_modern_header_is_not_read_as_a_legacy_one():
assert scan_line(MODERN_LINE) == ["sha256"]
assert scan_line(LEGACY_LINE) == ["sha1"]
assert scan_line("nothing to see here") == []
def test_a_line_naming_both_headers_reports_both():
line = 'const h = req.headers["x-hub-signature-256"] ?? req.headers["x-hub-signature"];'
assert scan_line(line) == ["sha256", "sha1"]
def test_the_runtime_spellings_are_the_same_header():
assert scan_line(WSGI_LINE) == ["sha256"]
assert scan_line("X_HUB_SIGNATURE") == ["sha1"]
assert normalized("X-Hub_Signature-256") == "x-hub-signature-256"
def test_the_scan_reports_line_numbers_and_never_lines():
text = "\n".join(["import os", LEGACY_LINE, "", MODERN_LINE])
hits = scan_source(text, "receiver/hooks.py")
assert hits == [("receiver/hooks.py", 2, "sha1"),
("receiver/hooks.py", 4, "sha256")]
rendered = [format_hit(h) for h in hits]
assert rendered[0] == "receiver/hooks.py:2 legacy X-Hub-Signature"
assert rendered[1] == "receiver/hooks.py:4 modern X-Hub-Signature-256"
assert not any("request.headers" in line for line in rendered)
def test_the_receiver_state_separates_only_legacy_from_both():
assert receiver_state([("a", 1, "sha1")]) == "sha1-only"
assert receiver_state([("a", 1, "sha256")]) == "sha256-only"
assert receiver_state([("a", 1, "sha256"), ("a", 1, "sha1")]) == "both"
assert receiver_state([]) == "none"
def test_a_masked_secret_is_presence_and_never_a_value():
assert secret_state(SECRET_SET) == "set"
assert secret_state(NO_SECRET) == "absent"
assert secret_state({"id": 3}) == "unknown"
safe = redacted_config(SECRET_SET["config"])
assert safe["secret"] == "<set>"
assert "********" not in str(safe)
def test_header_names_are_matched_exactly_and_values_dropped():
sent = {"X-Hub-Signature": "sha1=deadbeef",
"X-Hub-Signature-256": "sha256=deadbeef",
"Content-Type": "application/json"}
assert signature_headers(sent) == {"sha256": True, "sha1": True}
assert signature_headers({"X-Hub-Signature-256": "x"}) == {"sha256": True, "sha1": False}
assert signature_headers({}) == {"sha256": False, "sha1": False}
assert "deadbeef" not in str(header_names(sent))
def test_delivery_headers_arrive_in_more_than_one_shape():
as_list = [{"name": "X-Hub-Signature-256", "value": "sha256=x"},
{"name": "Content-Type", "value": "application/json"}]
assert signature_headers(as_list)["sha256"] is True
assert signature_headers(["X-Hub-Signature: sha1=x"])["sha1"] is True
assert signature_headers(None) == {"sha256": False, "sha1": False}
def test_a_legacy_receiver_is_the_finding():
state, detail = verdict("set", {"sha256": True, "sha1": True}, "sha1-only")
assert state == "sha1-only"
assert "being ignored" in detail
assert "constant-time" in repair(state)
def test_accepting_both_headers_is_still_a_finding():
state, detail = verdict("set", {"sha256": True, "sha1": True}, "both")
assert state == "both-accepted"
assert "weaker" in detail
def test_a_hook_with_no_secret_is_sent_to_a_different_note():
state, detail = verdict("absent", None, "sha1-only")
assert state == "no-secret"
assert "different and larger problem" in detail
def test_with_no_source_the_script_declines_to_guess():
state, detail = verdict("set", {"sha256": True, "sha1": True}, None)
assert state == "not-scanned"
assert "not visible from the API" in detail
def test_finding_nothing_is_not_reported_as_finding_a_problem():
state, detail = verdict("set", {"sha256": True, "sha1": True}, "none")
assert state == "no-verification-found"
assert "at runtime" in detail
def test_a_correct_receiver_passes():
state, _ = verdict("set", {"sha256": True, "sha1": True}, "sha256-only")
assert state == "sha256-only"
assert repair(state).startswith("nothing")
import { test } from 'node:test';
import assert from 'node:assert/strict';
import {
formatHit, headerNames, normalized, receiverState, redactedConfig,
repair, scanLine, scanSource, secretState, signatureHeaders, verdict,
} from './github-hook-signature-headers.mjs';
const MODERN_LINE = 'const sig = req.headers["X-Hub-Signature-256"];';
const LEGACY_LINE = 'const sig = req.headers["X-Hub-Signature"];';
const WSGI_LINE = 'sig = environ["HTTP_X_HUB_SIGNATURE_256"]';
const SECRET_SET = {
id: 1,
config: { url: 'https://example.com/hook', secret: '********', content_type: 'json' },
};
const NO_SECRET = {
id: 2,
config: { url: 'https://example.com/hook', content_type: 'json' },
};
test('the modern header is not read as a legacy one', () => {
assert.deepEqual(scanLine(MODERN_LINE), ['sha256']);
assert.deepEqual(scanLine(LEGACY_LINE), ['sha1']);
assert.deepEqual(scanLine('nothing to see here'), []);
});
test('a line naming both headers reports both', () => {
const line = 'const h = req.headers["x-hub-signature-256"] ?? req.headers["x-hub-signature"];';
assert.deepEqual(scanLine(line), ['sha256', 'sha1']);
});
test('the runtime spellings are the same header', () => {
assert.deepEqual(scanLine(WSGI_LINE), ['sha256']);
assert.deepEqual(scanLine('X_HUB_SIGNATURE'), ['sha1']);
assert.equal(normalized('X-Hub_Signature-256'), 'x-hub-signature-256');
});
test('the scan reports line numbers and never lines', () => {
const text = ['import os', LEGACY_LINE, '', MODERN_LINE].join('\n');
const hits = scanSource(text, 'receiver/hooks.js');
assert.deepEqual(hits, [
['receiver/hooks.js', 2, 'sha1'],
['receiver/hooks.js', 4, 'sha256'],
]);
const rendered = hits.map(formatHit);
assert.equal(rendered[0], 'receiver/hooks.js:2 legacy X-Hub-Signature');
assert.equal(rendered[1], 'receiver/hooks.js:4 modern X-Hub-Signature-256');
assert.ok(!rendered.some((line) => line.includes('req.headers')));
});
test('the receiver state separates only legacy from both', () => {
assert.equal(receiverState([['a', 1, 'sha1']]), 'sha1-only');
assert.equal(receiverState([['a', 1, 'sha256']]), 'sha256-only');
assert.equal(receiverState([['a', 1, 'sha256'], ['a', 1, 'sha1']]), 'both');
assert.equal(receiverState([]), 'none');
});
test('a masked secret is presence and never a value', () => {
assert.equal(secretState(SECRET_SET), 'set');
assert.equal(secretState(NO_SECRET), 'absent');
assert.equal(secretState({ id: 3 }), 'unknown');
const safe = redactedConfig(SECRET_SET.config);
assert.equal(safe.secret, '<set>');
assert.ok(!JSON.stringify(safe).includes('********'));
});
test('header names are matched exactly and values dropped', () => {
const sent = {
'X-Hub-Signature': 'sha1=deadbeef',
'X-Hub-Signature-256': 'sha256=deadbeef',
'Content-Type': 'application/json',
};
assert.deepEqual(signatureHeaders(sent), { sha256: true, sha1: true });
assert.deepEqual(signatureHeaders({ 'X-Hub-Signature-256': 'x' }),
{ sha256: true, sha1: false });
assert.deepEqual(signatureHeaders({}), { sha256: false, sha1: false });
assert.ok(!JSON.stringify(headerNames(sent)).includes('deadbeef'));
});
test('delivery headers arrive in more than one shape', () => {
const asList = [
{ name: 'X-Hub-Signature-256', value: 'sha256=x' },
{ name: 'Content-Type', value: 'application/json' },
];
assert.equal(signatureHeaders(asList).sha256, true);
assert.equal(signatureHeaders(['X-Hub-Signature: sha1=x']).sha1, true);
assert.deepEqual(signatureHeaders(null), { sha256: false, sha1: false });
});
test('a legacy receiver is the finding', () => {
const [state, detail] = verdict('set', { sha256: true, sha1: true }, 'sha1-only');
assert.equal(state, 'sha1-only');
assert.match(detail, /being ignored/);
assert.match(repair(state), /constant-time/);
});
test('accepting both headers is still a finding', () => {
const [state, detail] = verdict('set', { sha256: true, sha1: true }, 'both');
assert.equal(state, 'both-accepted');
assert.match(detail, /weaker/);
});
test('a hook with no secret is sent to a different note', () => {
const [state, detail] = verdict('absent', null, 'sha1-only');
assert.equal(state, 'no-secret');
assert.match(detail, /different and larger problem/);
});
test('with no source the script declines to guess', () => {
const [state, detail] = verdict('set', { sha256: true, sha1: true }, null);
assert.equal(state, 'not-scanned');
assert.match(detail, /not visible from the API/);
});
test('finding nothing is not reported as finding a problem', () => {
const [state, detail] = verdict('set', { sha256: true, sha1: true }, 'none');
assert.equal(state, 'no-verification-found');
assert.match(detail, /at runtime/);
});
test('a correct receiver passes', () => {
const [state] = verdict('set', { sha256: true, sha1: true }, 'sha256-only');
assert.equal(state, 'sha256-only');
assert.ok(repair(state).startsWith('nothing'));
});
FAQ
Is the SHA-1 header actually insecure?
The practical answer is that HMAC-SHA1 has held up better than bare SHA-1, and nobody is forging your webhook payloads this afternoon. The reason to move is not an imminent break, it is that you are choosing the weaker of two digests that are already both being sent to you, at no cost and with no migration, and that every security questionnaire and every auditor from now on will ask about it. GitHub keeps sending the SHA-1 header for compatibility, not as a recommendation.
Why does the script read my source instead of just checking the API?
Because the API genuinely cannot answer this. GitHub records what it sent and what your server replied; there is no field anywhere describing which header your code read. A script that stopped at the API could only ever print a recommendation. Reading the source turns it into a finding for the ordinary case where the header name is a literal in the code, and the script is explicit that a name built at runtime or wrapped in a framework helper is invisible to it.
It found nothing at all in my receiver. Is that good?
No, and the script does not call it good. Finding neither header name means one of three things: the receiver does not verify signatures, the header name is constructed rather than written out, or the scan was pointed at the wrong directory. Only the first is a serious problem and it is the most serious one in this note, so the state is reported as its own thing rather than being folded into a pass. Check by hand which of the three you are in.
We check the SHA-256 header and fall back to SHA-1 for old clients. Is that fine?
There are no old clients. GitHub is the only sender, and it sends both headers on every delivery, so a fallback path cannot be reached by any legitimate request that could not also satisfy the modern check. What it can be reached by is a request carrying only a SHA-1 signature, which is to say the exact request you would want rejected. Accepting either header leaves you as strong as the weaker one, so the script reports it as a finding.
Does any of this change what I do about the raw body?
It is the part people get wrong immediately after switching headers. The HMAC is computed over the exact bytes GitHub sent, so a framework that parses JSON and hands you a dict has already destroyed the input: re-serialising it produces different bytes and a signature that never matches. Capture the raw body before anything parses it, verify against that, and only then parse. This is also why a form-encoded hook breaks naive verification, which is a separate note.
Related field notes
- A webhook with no secret sends no signature
- Deliveries failing where nobody reads the log
- A webhook posting to a plain http:// URL
Sources
Every figure in this note is traced to one of these. Prices are list rates and change — check them for your own region before acting.
- Validating webhook deliveries — GitHub Docs
- Repository webhooks — GitHub REST API
- Best practices for using webhooks — GitHub Docs
- Webhooks — GitHub Apps REST API
If your setup is misbehaving in a way this note does not cover, message me on LinkedIn with what you are seeing.
