Diagnostic Twilio

one smart quote triples your segment count and your bill

Nothing failed. Every message says delivered, every customer got it, and the only thing that changed is the invoice: the SMS line is three times what it was on the same send volume. Somewhere in a template, an edit made in a rich text box replaced a straight apostrophe with a curly one. Every message that template renders now costs three segments instead of one, and there is no error code anywhere in the account to say so.

Read-only key Python and Node.js Tests included
Red and white love print textile
Photo by Tamanna Rumee on Unsplash
The short answer

Page GET /2010-04-01/Accounts/{AccountSid}/Messages.json?DateSent>=YYYY-MM-DD&PageSize=1000 and recompute the encoding from body yourself: GSM-7 if every character is in the GSM 03.38 alphabet, UCS-2 if even one is not. Compare your segment count against num_segments.

UCS-2 fits 70 characters in a single segment and 67 in a concatenated one, against 160 and 153 for GSM-7. Then read smart_encoding on each Messaging Service to see whether the mitigation is even on.

The problem in plain words

SMS has two alphabets. GSM-7 packs 160 characters into one segment; UCS-2 packs 70. The choice is not per-character, it is per-message: a single character outside the GSM alphabet forces the entire body into UCS-2, and a 150 character message that used to be one segment becomes three.

The characters that do it are not exotic. A curly apostrophe from a word processor, an en dash from a designer's copy deck, a non-breaking space pasted out of a spreadsheet, an emoji added to a campaign because it lifted click-through by two percent. None of them look different in the console. The message renders identically on the handset. Delivery is unaffected.

So the failure is purely financial, and it shows up in the only place nobody wires an alert to: the monthly bill, six weeks later, as a number somebody explains away as growth.

Copy editedstraight quote tocurlyBody leavesGSM-7one characterdecides70 per segmentinstead of 160Segments tripleno error codeBill triplesfound six weekslater
Every step succeeds and every message is delivered. The only thing that changes is the number of segments each send is billed for.

Why it happens

One character decides the encoding for the whole body. There is no partial encoding and no per-character cost. The message is GSM-7 or it is not, and the cost of the sixty-ninth ordinary character is decided by one curly quote in the first line.

The arithmetic is a cliff, not a slope. Concatenated segments hold 153 GSM-7 characters or 67 UCS-2 characters, because the concatenation header eats part of each one. A 150 character body goes from one segment to three — a 200% increase for a character nobody typed deliberately.

Nothing errors. No error_code, status delivered, no alert, no Debugger entry. The single field that records what happened is num_segments, and it is an integer on a resource nobody reads after the send succeeds.

Smart Encoding is a per-service toggle. It transliterates the common offenders for you, and it is the correct fix — but it applies to the Messaging Service it is set on. A second service for a new tenant, a service cloned for staging, or a send with a bare From and no service at all has none of it.

The fix, as a flow

The script recomputes the encoding from the body rather than trusting num_segments, because the billed count tells you the cost while the recomputation tells you which character caused it.

Body recomputed offlinealphabet, units, segmentsAll GSM-7cheapest it can beBilled under raw costSmart Encoding is coveringEmoji or non LatinUCS-2 is correct hereOnly smart punctuationextra segments every send
An emoji and a curly quote are not the same finding: one is a price worth paying and the other is a substitution nobody chose.

How to fix it

Page the Messages list over a window

GET /2010-04-01/Accounts/{AccountSid}/Messages.json?DateSent>=YYYY-MM-DD&PageSize=1000, following next_page_uri. There is nothing to filter on here — no error code exists for this — so bound the sweep by days and by a hard message cap and read the bodies.

Recompute the encoding from the body

GSM-7 if every character is in the GSM 03.38 basic set or its extension table; UCS-2 otherwise. The extension characters — ^ { } [ ] ~ | € and backslash — are GSM-7 but cost two units each, which is the detail that makes a hand-rolled length check wrong by a segment.

Count segments the way the carrier does

160 units in a single GSM-7 segment, 153 per segment once concatenated. 70 and 67 for UCS-2, counted in UTF-16 code units, so anything outside the Basic Multilingual Plane — every emoji — costs two.

Compare your count with num_segments

If Twilio billed fewer segments than the raw body would cost, Smart Encoding already rewrote that message on the way out and the template is still wrong — it is just being paid for by a setting. If the counts match, nothing is mitigating anything.

Turn on Smart Encoding, then fix the template

POST https://messaging.twilio.com/v1/Services/{ServiceSid} with SmartEncoding=true (Console → Messaging → Services → Content Settings), and normalise curly quotes and dashes where the template is authored. Corroborate the saving afterwards with GET /2010-04-01/Accounts/{AccountSid}/Usage/Records/Daily.json?Category=sms-outbound, comparing count against usage.

How to check it worked

Re-run over the same window after the change. The extra segment count should be zero, and anything still in UCS-2 should be there because it genuinely has to be.

python3 twilio_segment_audit.py --days 7
# 3 sender(s) over 7 day(s), 0 extra segment(s) from avoidable UCS-2

The full code

The interesting half of this script never touches the network. Deciding GSM-7 against UCS-2, counting units with the extension table, and working out what the same body would have cost after transliteration is all arithmetic over a string — so it is a pure function with the alphabet written out in full, and the tests exercise it offline. The network half is one paginated GET over the Messages list and one over the Messaging Services.

Get this script on GitHub Follow @allanninal Python and Node.js, with tests. Read only, it never writes. One of 40 Twilio fixes, free and open source.
twilio_segment_audit.py
"""Report Twilio messages inflated into UCS-2 by a handful of characters.

Read only. GET requests and nothing else: give this an API Key with read access
rather than the account auth token. The repair is printed, never performed,
because this script holds a credential to an account that can send messages and
spend money.
"""
import argparse
import datetime as dt
import logging
import os
import sys

import requests

logging.basicConfig(level=logging.INFO, format="%(asctime)s %(levelname)s %(message)s")
log = logging.getLogger("twilio_segment_audit")

HOST = "https://api.twilio.com"
BASE = HOST + "/2010-04-01"
MESSAGING = "https://messaging.twilio.com/v1"

# GSM 03.38, the alphabet a single segment of 160 characters is drawn from.
GSM_BASIC = set(
    "@£$¥èéùìòÇØøÅåΔ_ΦΓΛΩΠΨΣΘΞÆæßÉ !#¤%&()*+,-./0123456789:;<=>?"
    "¡ABCDEFGHIJKLMNOPQRSTUVWXYZÄÖÑܧ¿abcdefghijklmnopqrstuvwxyzäöñüà")
# The four that cannot sit in the literal above without fighting the quoting:
# double quote, apostrophe, newline, carriage return.
GSM_BASIC.update({chr(34), chr(39), chr(10), chr(13)})

# The extension table. These are GSM-7, but each one costs two units, which is
# the detail that makes a naive len() check wrong by a whole segment.
GSM_EXT = set("^{}[~]|€")
GSM_EXT.add(chr(92))  # backslash

GSM_SINGLE, GSM_MULTI = 160, 153
UCS_SINGLE, UCS_MULTI = 70, 67

# What Smart Encoding substitutes, near enough: the characters a rich text
# editor inserts silently and that nobody meant to pay three times for.
TRANSLITERATE = {
    "‘": chr(39), "’": chr(39), "‚": chr(39), "‛": chr(39),
    "′": chr(39), "´": chr(39), "ʼ": chr(39),
    "“": chr(34), "”": chr(34), "„": chr(34),
    "«": chr(34), "»": chr(34),
    "–": "-", "—": "-", "−": "-",
    "…": "...", " ": " ", "•": "*", "™": "TM",
}


def sms_encoding(body):
    """GSM-7 if every character is in the GSM alphabet, UCS-2 otherwise. Pure.

    The choice is per message, not per character: one character outside the
    alphabet moves the entire body to UCS-2 and 70 characters a segment.
    """
    for c in str(body or ""):
        if c not in GSM_BASIC and c not in GSM_EXT:
            return "UCS-2"
    return "GSM-7"


def segments(body):
    """Return (encoding, units, segment_count) for a body. Pure.

    Units, not characters: an extension character costs two in GSM-7, and a
    character outside the Basic Multilingual Plane (every emoji) costs two
    UTF-16 code units in UCS-2.
    """
    text = str(body or "")
    encoding = sms_encoding(text)
    if encoding == "GSM-7":
        units = sum(2 if c in GSM_EXT else 1 for c in text)
        single, multi = GSM_SINGLE, GSM_MULTI
    else:
        units = sum(2 if ord(c) > 0xFFFF else 1 for c in text)
        single, multi = UCS_SINGLE, UCS_MULTI
    if units <= single:
        return (encoding, units, 1)
    return (encoding, units, -(-units // multi))


def offenders(body):
    """Every distinct character forcing UCS-2, with its substitute or None.

    Pure. None means nothing can stand in for it: an emoji, or a script that is
    simply not Latin, in which case UCS-2 is correct and the cost is real.
    """
    out, seen = [], set()
    for c in str(body or ""):
        if c in GSM_BASIC or c in GSM_EXT or c in seen:
            continue
        seen.add(c)
        out.append((c, TRANSLITERATE.get(c)))
    return out


def transliterate(body):
    """The body as Smart Encoding would rewrite it. Pure."""
    return "".join(TRANSLITERATE.get(c, c) for c in str(body or ""))


def describe(chars):
    return ", ".join("%s (U+%04X)" % (c, ord(c)) for c in chars)


def verdict(body, reported=None):
    """Classify one message body. Pure, and the whole point of this script.

    `reported` is num_segments as Twilio billed it. When it is lower than the
    raw body would cost, Smart Encoding rewrote the message on the way out: the
    template is still wrong, a setting is just paying for it.

    Returns (state, detail).
    """
    text = str(body or "")
    encoding, units, count = segments(text)
    if encoding == "GSM-7":
        return ("gsm-7", "%d segment(s), GSM-7, %d unit(s)" % (count, units))

    if reported is not None:
        try:
            billed = int(reported)
        except (TypeError, ValueError):
            billed = None
        if billed is not None and billed < count:
            return ("smart-encoded",
                    "billed %d segment(s), not the %d this body costs as UCS-2: "
                    "Smart Encoding rewrote it on the way out, so the template "
                    "is still wrong and a setting is paying for it."
                    % (billed, count))

    found = offenders(text)
    fixable = [c for c, sub in found if sub is not None]
    stuck = [c for c, sub in found if sub is None]

    if stuck:
        return ("ucs2-required",
                "%d segment(s) as UCS-2, %d unit(s). Nothing to strip: %s cannot "
                "be transliterated, so UCS-2 is correct here and the cost is "
                "expected rather than accidental."
                % (count, units, describe(stuck[:4])))

    clean = segments(transliterate(text))[2]
    return ("ucs2-avoidable",
            "%d segment(s) as UCS-2 against %d after transliteration: %d extra "
            "segment(s) on every send of this body, caused by %s."
            % (count, clean, count - clean, describe(fixable[:4])))


def tally(messages):
    """Bucket outbound messages by sender and add up the avoidable segments.

    Pure. Inbound messages are skipped: their encoding is the sender's problem
    and you are not billed by the segment for receiving them.
    """
    rows = {}
    for m in messages:
        if str(m.get("direction") or "").startswith("inbound"):
            continue
        body = str(m.get("body") or "")
        if not body.strip():
            continue
        key = m.get("messaging_service_sid") or m.get("from") or "unknown sender"
        row = rows.setdefault(key, {"total": 0, "ucs2": 0, "extra": 0,
                                    "chars": [], "sids": []})
        row["total"] += 1
        state, _ = verdict(body, m.get("num_segments"))
        if state == "gsm-7":
            continue
        row["ucs2"] += 1
        if state == "ucs2-avoidable":
            row["extra"] += segments(body)[2] - segments(transliterate(body))[2]
        for c, _sub in offenders(body):
            if c not in row["chars"]:
                row["chars"].append(c)
        if len(row["sids"]) < 3:
            row["sids"].append(m.get("sid"))
    return rows


def get(session, url, **params):
    r = session.get(url, params=params, timeout=30)
    if r.status_code in (401, 403):
        raise SystemExit("%d from Twilio: check TWILIO_ACCOUNT_SID and that the "
                         "API key belongs to that account with read access"
                         % r.status_code)
    r.raise_for_status()
    return r.json()


def list_messages(session, account, since, limit):
    """Page Messages.json. Nothing to filter on: this failure has no error
    code, so the window and the cap are the only bounds there are."""
    url = "%s/Accounts/%s/Messages.json" % (BASE, account)
    params = {"PageSize": 1000, "DateSent>=": since}
    out = []
    while url and len(out) < limit:
        page = get(session, url, **params)
        out.extend(page.get("messages", []))
        nxt = page.get("next_page_uri")
        url, params = (HOST + nxt) if nxt else None, {}
    return out[:limit]


def smart_encoding_by_service(session):
    """Map service sid to its smart_encoding flag. next_page_url is absolute on
    this API, unlike the relative next_page_uri on the 2010 one."""
    url = "%s/Services" % MESSAGING
    params = {"PageSize": 50}
    out = {}
    while url:
        page = get(session, url, **params)
        for s in page.get("services", []):
            out[s.get("sid")] = bool(s.get("smart_encoding"))
        url = (page.get("meta") or {}).get("next_page_url")
        params = {}
    return out


def main():
    ap = argparse.ArgumentParser(description=__doc__)
    ap.add_argument("--days", type=int, default=7,
                    help="how far back to read the Messages list")
    ap.add_argument("--max-messages", type=int, default=20000,
                    help="stop paging after this many messages")
    args = ap.parse_args()

    account = os.environ.get("TWILIO_ACCOUNT_SID")
    key = os.environ.get("TWILIO_API_KEY")
    secret = os.environ.get("TWILIO_API_SECRET")
    if not (account and key and secret):
        log.error("set TWILIO_ACCOUNT_SID, TWILIO_API_KEY and TWILIO_API_SECRET "
                  "(an API Key with read access, not the auth token)")
        return 2

    session = requests.Session()
    session.auth = (key, secret)

    since = (dt.date.today() - dt.timedelta(days=args.days)).isoformat()
    messages = list_messages(session, account, since, args.max_messages)
    if not messages:
        log.info("no messages sent since %s", since)
        return 0

    senders = tally(messages)
    services = smart_encoding_by_service(session)

    extra = 0
    for sender, stats in sorted(senders.items()):
        if not stats["ucs2"]:
            log.info("%-15s %s  %d message(s), all GSM-7",
                     "gsm-7", sender, stats["total"])
            continue
        extra += stats["extra"]
        state = "inflated" if stats["extra"] else "ucs2"
        log.warning("%-15s %s  %d of %d message(s) in UCS-2, %d extra "
                    "segment(s) over the window, offenders: %s",
                    state, sender, stats["ucs2"], stats["total"], stats["extra"],
                    describe(stats["chars"][:6]))
        log.warning("  message sids: %s", ", ".join(str(s) for s in stats["sids"]))
        if str(sender).startswith("MG"):
            if services.get(sender):
                log.warning("  smart_encoding is already true on %s: what is "
                            "left is genuinely non-GSM content, or a template "
                            "using characters the substitution table misses.",
                            sender)
            else:
                log.warning("  repair: POST %s/Services/%s SmartEncoding=true, "
                            "and normalise curly quotes and dashes where the "
                            "template is authored.", MESSAGING, sender)
        else:
            log.warning("  repair: this sent with a bare From, so no Messaging "
                        "Service and no Smart Encoding to enable. Send through "
                        "a service, or normalise the body before the call.")

    log.info("%d sender(s) over %d day(s), %d extra segment(s) from avoidable "
             "UCS-2", len(senders), args.days, extra)
    return 1 if extra else 0


if __name__ == "__main__":
    sys.exit(main())
twilio-segment-audit.mjs
/**
 * Report Twilio messages inflated into UCS-2 by a handful of characters.
 *
 * Read only. GET requests and nothing else: give this an API Key with read
 * access rather than the account auth token. The repair is printed, never
 * performed.
 */
const HOST = 'https://api.twilio.com';
const BASE = `${HOST}/2010-04-01`;
const MESSAGING = 'https://messaging.twilio.com/v1';

// GSM 03.38, the alphabet a single segment of 160 characters is drawn from.
const GSM_BASIC = new Set(
  '@£$¥èéùìòÇØøÅåΔ_ΦΓΛΩΠΨΣΘΞÆæßÉ !#¤%&()*+,-./0123456789:;<=>?' +
  '¡ABCDEFGHIJKLMNOPQRSTUVWXYZÄÖÑܧ¿abcdefghijklmnopqrstuvwxyzäöñüà');
// Double quote, apostrophe, newline and carriage return, kept out of the
// literal above so it does not fight the quoting.
for (const code of [34, 39, 10, 13]) GSM_BASIC.add(String.fromCharCode(code));

// The extension table: GSM-7, but two units each.
const GSM_EXT = new Set('^{}[~]|€');
GSM_EXT.add(String.fromCharCode(92)); // backslash

const GSM_SINGLE = 160, GSM_MULTI = 153;
const UCS_SINGLE = 70, UCS_MULTI = 67;

// What Smart Encoding substitutes, near enough.
const TRANSLITERATE = new Map(Object.entries({
  '‘': "'", '’': "'", '‚': "'", '‛': "'",
  '′': "'", '´': "'", 'ʼ': "'",
  '“': '"', '”': '"', '„': '"', '«': '"', '»': '"',
  '–': '-', '—': '-', '−': '-',
  '…': '...', ' ': ' ', '•': '*', '™': 'TM',
}));

/**
 * GSM-7 if every character is in the GSM alphabet, UCS-2 otherwise. Pure. The
 * choice is per message: one character outside the alphabet moves the whole
 * body to 70 characters a segment.
 */
export function smsEncoding(body) {
  for (const c of String(body ?? '')) {
    if (!GSM_BASIC.has(c) && !GSM_EXT.has(c)) return 'UCS-2';
  }
  return 'GSM-7';
}

/**
 * Return [encoding, units, segmentCount]. Pure. Units, not characters: an
 * extension character costs two in GSM-7, and anything outside the Basic
 * Multilingual Plane costs two UTF-16 code units in UCS-2.
 */
export function segments(body) {
  const text = String(body ?? '');
  const encoding = smsEncoding(text);
  let units = 0;
  for (const c of text) {
    if (encoding === 'GSM-7') units += GSM_EXT.has(c) ? 2 : 1;
    else units += c.codePointAt(0) > 0xFFFF ? 2 : 1;
  }
  const single = encoding === 'GSM-7' ? GSM_SINGLE : UCS_SINGLE;
  const multi = encoding === 'GSM-7' ? GSM_MULTI : UCS_MULTI;
  return [encoding, units, units <= single ? 1 : Math.ceil(units / multi)];
}

/**
 * Every distinct character forcing UCS-2, with its substitute or null. Pure.
 * null means nothing can stand in for it, and UCS-2 is correct.
 */
export function offenders(body) {
  const out = [];
  const seen = new Set();
  for (const c of String(body ?? '')) {
    if (GSM_BASIC.has(c) || GSM_EXT.has(c) || seen.has(c)) continue;
    seen.add(c);
    out.push([c, TRANSLITERATE.get(c) ?? null]);
  }
  return out;
}

/** The body as Smart Encoding would rewrite it. Pure. */
export function transliterate(body) {
  return [...String(body ?? '')].map((c) => TRANSLITERATE.get(c) ?? c).join('');
}

export function describe(chars) {
  return chars.map((c) =>
    `${c} (U+${c.codePointAt(0).toString(16).toUpperCase().padStart(4, '0')})`)
    .join(', ');
}

/**
 * Classify one message body. Pure, and the whole point of this script.
 * `reported` is num_segments as Twilio billed it; lower than the raw cost means
 * Smart Encoding rewrote the message on the way out. Returns [state, detail].
 */
export function verdict(body, reported = null) {
  const text = String(body ?? '');
  const [encoding, units, count] = segments(text);
  if (encoding === 'GSM-7') {
    return ['gsm-7', `${count} segment(s), GSM-7, ${units} unit(s)`];
  }

  if (reported !== null && reported !== undefined) {
    const billed = Number(reported);
    if (Number.isFinite(billed) && billed < count) {
      return ['smart-encoded',
        `billed ${billed} segment(s), not the ${count} this body costs as ` +
        'UCS-2: Smart Encoding rewrote it on the way out, so the template is ' +
        'still wrong and a setting is paying for it.'];
    }
  }

  const found = offenders(text);
  const fixable = found.filter(([, sub]) => sub !== null).map(([c]) => c);
  const stuck = found.filter(([, sub]) => sub === null).map(([c]) => c);

  if (stuck.length) {
    return ['ucs2-required',
      `${count} segment(s) as UCS-2, ${units} unit(s). Nothing to strip: ` +
      `${describe(stuck.slice(0, 4))} cannot be transliterated, so UCS-2 is ` +
      'correct here and the cost is expected rather than accidental.'];
  }

  const clean = segments(transliterate(text))[2];
  return ['ucs2-avoidable',
    `${count} segment(s) as UCS-2 against ${clean} after transliteration: ` +
    `${count - clean} extra segment(s) on every send of this body, caused by ` +
    `${describe(fixable.slice(0, 4))}.`];
}

/**
 * Bucket outbound messages by sender and add up the avoidable segments. Pure.
 */
export function tally(messages) {
  const rows = new Map();
  for (const m of messages) {
    if (String(m.direction ?? '').startsWith('inbound')) continue;
    const body = String(m.body ?? '');
    if (!body.trim()) continue;
    const key = m.messaging_service_sid || m.from || 'unknown sender';
    if (!rows.has(key)) rows.set(key, { total: 0, ucs2: 0, extra: 0, chars: [], sids: [] });
    const row = rows.get(key);
    row.total += 1;
    const [state] = verdict(body, m.num_segments ?? null);
    if (state === 'gsm-7') continue;
    row.ucs2 += 1;
    if (state === 'ucs2-avoidable') {
      row.extra += segments(body)[2] - segments(transliterate(body))[2];
    }
    for (const [c] of offenders(body)) if (!row.chars.includes(c)) row.chars.push(c);
    if (row.sids.length < 3) row.sids.push(m.sid);
  }
  return rows;
}

function authHeader(key, secret) {
  return `Basic ${Buffer.from(`${key}:${secret}`).toString('base64')}`;
}

async function get(auth, url, params = {}) {
  const u = new URL(url);
  for (const [k, v] of Object.entries(params)) u.searchParams.set(k, v);
  const res = await fetch(u, { headers: { Authorization: auth } });
  if (res.status === 401 || res.status === 403) {
    throw new Error(`${res.status} from Twilio: check TWILIO_ACCOUNT_SID and ` +
                    'that the API key belongs to that account with read access');
  }
  if (!res.ok) throw new Error(`${res.status} from ${u.pathname}`);
  return res.json();
}

async function listMessages(auth, account, since, limit) {
  let url = `${BASE}/Accounts/${account}/Messages.json`;
  let params = { PageSize: 1000, 'DateSent>=': since };
  const out = [];
  while (url && out.length < limit) {
    const page = await get(auth, url, params);
    out.push(...(page.messages ?? []));
    url = page.next_page_uri ? HOST + page.next_page_uri : null;
    params = {};
  }
  return out.slice(0, limit);
}

async function smartEncodingByService(auth) {
  let url = `${MESSAGING}/Services`;
  let params = { PageSize: 50 };
  const out = new Map();
  while (url) {
    const page = await get(auth, url, params);
    for (const s of page.services ?? []) out.set(s.sid, Boolean(s.smart_encoding));
    url = page.meta?.next_page_url ?? null;
    params = {};
  }
  return out;
}

function flag(name, fallback) {
  const i = process.argv.indexOf(name);
  return i === -1 ? fallback : Number(process.argv[i + 1]);
}

async function main() {
  const account = process.env.TWILIO_ACCOUNT_SID;
  const key = process.env.TWILIO_API_KEY;
  const secret = process.env.TWILIO_API_SECRET;
  if (!account || !key || !secret) {
    console.error('set TWILIO_ACCOUNT_SID, TWILIO_API_KEY and TWILIO_API_SECRET ' +
                  '(an API Key with read access, not the auth token)');
    process.exitCode = 2;
    return;
  }
  const auth = authHeader(key, secret);
  const days = flag('--days', 7);
  const since = new Date(Date.now() - days * 86400000).toISOString().slice(0, 10);

  const messages = await listMessages(auth, account, since, flag('--max-messages', 20000));
  if (messages.length === 0) {
    console.log(`no messages sent since ${since}`);
    return;
  }

  const senders = tally(messages);
  const services = await smartEncodingByService(auth);

  let extra = 0;
  for (const sender of [...senders.keys()].sort()) {
    const stats = senders.get(sender);
    if (!stats.ucs2) {
      console.log(`gsm-7           ${sender}  ${stats.total} message(s), all GSM-7`);
      continue;
    }
    extra += stats.extra;
    const state = stats.extra ? 'inflated' : 'ucs2';
    console.warn(`${state.padEnd(15)} ${sender}  ${stats.ucs2} of ${stats.total} ` +
                 `message(s) in UCS-2, ${stats.extra} extra segment(s) over the ` +
                 `window, offenders: ${describe(stats.chars.slice(0, 6))}`);
    console.warn(`  message sids: ${stats.sids.join(', ')}`);
    if (String(sender).startsWith('MG')) {
      if (services.get(sender)) {
        console.warn(`  smart_encoding is already true on ${sender}: what is left ` +
                     'is genuinely non-GSM content, or characters the ' +
                     'substitution table misses.');
      } else {
        console.warn(`  repair: POST ${MESSAGING}/Services/${sender} ` +
                     'SmartEncoding=true, and normalise curly quotes and dashes ' +
                     'where the template is authored.');
      }
    } else {
      console.warn('  repair: this sent with a bare From, so no Messaging Service ' +
                   'and no Smart Encoding to enable. Send through a service, or ' +
                   'normalise the body before the call.');
    }
  }

  console.log(`${senders.size} sender(s) over ${days} day(s), ${extra} extra ` +
              'segment(s) from avoidable UCS-2');
  process.exitCode = extra ? 1 : 0;
}

// Only run when invoked directly, so importing this module in the tests does not
// run main(), fail on the missing credentials and set a non-zero exit code.
if (import.meta.url === `file://${process.argv[1]}`) {
  main().catch((err) => { console.error(err.message); process.exitCode = 2; });
}

Add a test

This is the classifier worth testing hardest, because every number it produces is money. The cases below pin the boundaries the arithmetic turns on: 160 characters against 161, an extension character costing two units, a 150 character body going from one segment to three on one curly apostrophe, and an emoji correctly reported as something no transliteration can rescue.

test_twilio_segment_audit.py
from twilio_segment_audit import (offenders, segments, sms_encoding, tally,
                                  transliterate, verdict)

CURLY = "’"     # right single quotation mark, the usual culprit
PARTY = "🎉"  # an emoji, outside the Basic Multilingual Plane


def test_plain_ascii_is_gsm7():
    assert sms_encoding("Your code is 123456") == "GSM-7"


def test_one_curly_apostrophe_moves_the_whole_body_to_ucs2():
    assert sms_encoding("It%ss ready" % CURLY) == "UCS-2"


def test_gsm7_segment_boundary_is_160_then_153():
    assert segments("a" * 160) == ("GSM-7", 160, 1)
    assert segments("a" * 161)[2] == 2
    assert segments("a" * 306)[2] == 2
    assert segments("a" * 307)[2] == 3


def test_extension_characters_cost_two_units():
    # 80 euro signs is 160 units: still one segment, but at half the characters.
    assert segments("€" * 80) == ("GSM-7", 160, 1)
    assert segments("€" * 81)[2] == 2


def test_ucs2_segment_boundary_is_70_then_67():
    body = "а" * 70  # Cyrillic
    assert segments(body) == ("UCS-2", 70, 1)
    assert segments("а" * 71)[2] == 2


def test_an_emoji_costs_two_utf16_units():
    encoding, units, count = segments(PARTY * 40)
    assert encoding == "UCS-2"
    assert units == 80
    assert count == 2


def test_one_smart_quote_turns_one_segment_into_three():
    body = "a" * 149 + CURLY
    state, detail = verdict(body)
    assert state == "ucs2-avoidable"
    assert segments(body)[2] == 3
    assert segments(transliterate(body))[2] == 1
    assert "2 extra segment(s)" in detail


def test_an_emoji_is_ucs2_that_nothing_can_fix():
    state, detail = verdict("Sale today " + PARTY)
    assert state == "ucs2-required"
    assert "cannot be transliterated" in detail


def test_billing_fewer_segments_means_smart_encoding_already_ran():
    state, detail = verdict("a" * 149 + CURLY, reported=1)
    assert state == "smart-encoded"
    assert "still wrong" in detail


def test_offenders_are_deduplicated_and_carry_their_substitute():
    found = offenders("%s%s ok %s" % (CURLY, CURLY, PARTY))
    assert [c for c, _ in found] == [CURLY, PARTY]
    assert found[0][1] == chr(39)
    assert found[1][1] is None


def test_tally_adds_up_the_avoidable_segments_per_sender():
    body = "a" * 149 + CURLY
    rows = tally([
        {"sid": "SM1", "messaging_service_sid": "MG1", "body": body},
        {"sid": "SM2", "messaging_service_sid": "MG1", "body": body},
        {"sid": "SM3", "messaging_service_sid": "MG1", "body": "plain text"},
        {"sid": "SM4", "from": "+15550001111", "direction": "inbound", "body": body},
    ])
    assert list(rows) == ["MG1"]
    assert rows["MG1"] == {"total": 3, "ucs2": 2, "extra": 4,
                           "chars": [CURLY], "sids": ["SM1", "SM2"]}
twilio-segment-audit.test.mjs
import { test } from 'node:test';
import assert from 'node:assert/strict';
import { offenders, segments, smsEncoding, tally, transliterate, verdict }
  from './twilio-segment-audit.mjs';

const CURLY = '’';       // right single quotation mark, the usual culprit
const PARTY = '🎉'; // an emoji, outside the Basic Multilingual Plane

test('plain ascii is gsm-7', () => {
  assert.equal(smsEncoding('Your code is 123456'), 'GSM-7');
});

test('one curly apostrophe moves the whole body to ucs-2', () => {
  assert.equal(smsEncoding(`It${CURLY}s ready`), 'UCS-2');
});

test('gsm-7 segment boundary is 160 then 153', () => {
  assert.deepEqual(segments('a'.repeat(160)), ['GSM-7', 160, 1]);
  assert.equal(segments('a'.repeat(161))[2], 2);
  assert.equal(segments('a'.repeat(306))[2], 2);
  assert.equal(segments('a'.repeat(307))[2], 3);
});

test('extension characters cost two units', () => {
  assert.deepEqual(segments('€'.repeat(80)), ['GSM-7', 160, 1]);
  assert.equal(segments('€'.repeat(81))[2], 2);
});

test('ucs-2 segment boundary is 70 then 67', () => {
  assert.deepEqual(segments('а'.repeat(70)), ['UCS-2', 70, 1]);
  assert.equal(segments('а'.repeat(71))[2], 2);
});

test('an emoji costs two utf-16 units', () => {
  assert.deepEqual(segments(PARTY.repeat(40)), ['UCS-2', 80, 2]);
});

test('one smart quote turns one segment into three', () => {
  const body = 'a'.repeat(149) + CURLY;
  const [state, detail] = verdict(body);
  assert.equal(state, 'ucs2-avoidable');
  assert.equal(segments(body)[2], 3);
  assert.equal(segments(transliterate(body))[2], 1);
  assert.match(detail, /2 extra segment\(s\)/);
});

test('an emoji is ucs-2 that nothing can fix', () => {
  const [state, detail] = verdict(`Sale today ${PARTY}`);
  assert.equal(state, 'ucs2-required');
  assert.match(detail, /cannot be transliterated/);
});

test('billing fewer segments means smart encoding already ran', () => {
  const [state, detail] = verdict('a'.repeat(149) + CURLY, 1);
  assert.equal(state, 'smart-encoded');
  assert.match(detail, /still wrong/);
});

test('offenders are deduplicated and carry their substitute', () => {
  const found = offenders(`${CURLY}${CURLY} ok ${PARTY}`);
  assert.deepEqual(found.map(([c]) => c), [CURLY, PARTY]);
  assert.equal(found[0][1], "'");
  assert.equal(found[1][1], null);
});

test('tally adds up the avoidable segments per sender', () => {
  const body = 'a'.repeat(149) + CURLY;
  const rows = tally([
    { sid: 'SM1', messaging_service_sid: 'MG1', body },
    { sid: 'SM2', messaging_service_sid: 'MG1', body },
    { sid: 'SM3', messaging_service_sid: 'MG1', body: 'plain text' },
    { sid: 'SM4', from: '+15550001111', direction: 'inbound', body },
  ]);
  assert.deepEqual([...rows.keys()], ['MG1']);
  assert.deepEqual(rows.get('MG1'), { total: 3, ucs2: 2, extra: 4,
                                      chars: [CURLY], sids: ['SM1', 'SM2'] });
});

FAQ

Which characters actually force UCS-2?

Anything outside the GSM 03.38 alphabet. In practice: curly quotes and apostrophes, en and em dashes, the ellipsis character, non-breaking spaces, bullets, most accented letters beyond the handful GSM includes, every emoji, and every non-Latin script. The GSM set does include à, ä, é, ö, ñ, ü, £, ¥ and €, which is why some accented copy stays cheap and some does not.

Why does one character cost so much?

Because the encoding is chosen for the whole message. GSM-7 fits 160 characters in a single segment and 153 in each concatenated one; UCS-2 fits 70 and 67. A 150 character body is one segment as GSM-7 and three as UCS-2, so a single curly apostrophe is a 200% price rise on every send of that template.

Does Smart Encoding fix all of it?

It fixes the accidental part. Smart Encoding substitutes look-alike GSM characters for the common offenders, which is exactly right for a curly quote that a rich text editor inserted. It cannot help an emoji or a Cyrillic word, and it should not: those messages need UCS-2, and the script reports them separately so you are not chasing a saving that does not exist.

Why recompute the encoding when num_segments is right there?

Because num_segments tells you the cost and not the cause. Recomputing from the body names the character responsible and says what the same message would have cost without it. Comparing the two numbers is also the only way to notice that Smart Encoding is quietly rescuing a template that is still wrong.

Can the script enable Smart Encoding itself?

No. Everything in this section is read-only, and this one holds a credential to an account that can spend money. It prints the exact POST against the Messaging Service, with the service SID, for you to run.

Related field notes

Sources

Every figure in this note is traced to one of these. Prices are list rates and change — check them for your own region before acting.

Stuck on a tricky one?

If your setup is misbehaving in a way this note does not cover, message me on LinkedIn with what you are seeing.
