Diagnostic GitHub API

the installation token was narrowed below what the job needs

The App is installed on the repository. You can see the installation, the repository is in its list, the permissions are generous, and one job gets 404 every time it touches that repository. The other four jobs, using the same App, on the same repository, are fine. Nobody has changed the App in months.

Read-only token Python and Node.js Tests included
White and blue magnetic card
Photo by Avery Evans on Unsplash
The short answer

The token that job is using was deliberately narrowed when it was minted. The endpoint that mints an installation access token accepts a repository list and a permission map in its body, and either of them cuts the token below what the installation actually holds. A token minted for repository A cannot see repository B, and one minted with only contents: read cannot touch issues, however wide the installation is.

Because the narrowing produces a 404 rather than a 403 for repositories, it reads as this does not exist rather than as you were not given this, which is why the search goes to the App and the installation and stays there. The fix is to widen the mint request, not the App.

Check it by asking the token what it can reach. GET /installation/repositories with that specific token returns exactly the repositories that token covers, and comparing that against what the job needs is the finding. There is a blind spot to state plainly: a token cannot report its own permission map. The mint response echoed it back to your code and there is no read that recovers it, so the permission half of this check is only possible if you kept that response.

The problem in plain words

Everything you would naturally check comes back clean, and each clean answer sends you further from the cause. The App is installed. The repository is in the installation. The permissions on the App are broad. The other jobs work. Every one of those facts is true and none of them is about the credential the failing job is holding, because the narrowing happened in four lines of minting code that nobody thinks of as configuration.

The 404 makes it worse, and it is doing the right thing. GitHub answers 404 rather than 403 when a credential is not entitled to know whether a private resource exists, which is correct and which means the response is deliberately indistinguishable from a typo in the repository name. So the first hour goes on spelling, then on whether the repository was renamed, then on whether it was archived, and all three investigations conclude that the repository is fine.

Then somebody widens the App. It does not help, because the App was never the constraint, and now the App holds permissions it does not need in order to fix a problem it did not have. Two rounds of that and the installation is carrying organization administration for a job that reads issue titles, which is a real security regression produced entirely by debugging in the wrong object.

Token mintednarrowone repo, onepermission404 on repo Bfrom one job onlyApp settingscheckedthe grant isgenerousReinstalled onBno change at allPermissionwidenedstill the same 404and the App is widened once more
Every other path using the same App works, which is exactly why the search goes to the App and not to the four lines that minted this particular token.

Why it happens

The mint request can narrow, never widen. The body of the token request accepts a repository list, a repository id list, and a permission map, and each is intersected with the installation's grant. You cannot mint a token more powerful than the installation; you can very easily mint one much less powerful, and there is no warning when you do, because narrowing is the feature.

Narrowing is good practice, which is why it is everywhere. A job that touches one repository should hold a token for one repository. The advice is right and the failure mode is its shadow: the narrowest sensible token for last quarter's job is too narrow for this quarter's, and the mint request is the last place anybody looks because it was written once and never revisited.

Repositories fail as 404 and permissions fail as 403. Two different symptoms from one cause, which is why they get filed as two different bugs. A repository outside the token's set does not exist as far as that token is concerned; a permission below what the endpoint needs produces the familiar refusal instead. The script checks both because the reader usually only has one of them.

A token cannot introspect its own permissions. This is the honest limit of the check. GET /installation/repositories tells you the repository half exactly, and nothing returns the permission map a token was minted with. The mint response contained it and only your own code ever saw it. So the script takes that saved response when you have it and, when you do not, says the permission half is unknown rather than implying the token is fine.

This is the opposite failure to a token that holds too much. Over-scoping is a security finding about a credential that can do more than its job; this is an availability finding about one that can do less. It is also not an installation that covers only some repositories: there the installation itself is narrow and every token from it is, here the installation is wide and one token is not.

The fix, as a flow

The narrowing happens in a request this script will never make. Minting a token is a write, so the script reads the token you already hold and asks what it can actually reach, then compares that against the repositories and permissions the job says it needs. One half of the comparison has a blind spot worth stating out loud: a token cannot report its own permission map, so that half comes from the mint response your own code received, or not at all.

What this token reachesagainst what the job asked forRepository out of reachwiden the mint, not the AppPermission below needthe mint asked for lessNarrowing not visibleno read returns the grantReach covers the jobthe 404 is about something else
The third row is the honest one. A token that looks fine may still be narrowed in a way no read can see.

How to fix it

Write down what this specific job needs

The repositories it touches, in owner/name form, and the permissions it uses with the level it uses them at. This is the comparison's right-hand side and it has to be the real list rather than the aspirational one; a job that reads one repository and writes a comment on another needs both named.

Ask the token what it can reach

GET /installation/repositories with the failing job's own token returns exactly the repositories that token covers, plus a repository_selection of all or selected. A selected here on an installation you know is org-wide is the narrowing, visible in one field.

Confirm per repository rather than trusting the list

For each repository the job needs, GET /repos/{owner}/{repo} with the same token. A 200 is reach, a 404 is not-in-this-token, and doing it directly catches the case where the list was truncated by pagination and you drew the wrong conclusion from a partial page.

Recover the permission map from the mint response, or admit you cannot

The response your minting code received echoes back permissions and repository_selection for the token it issued. If you log or keep that, feed it in and the permission half becomes exact. If you do not, no read recovers it, and the script reports the permission half as unknown rather than passing it.

Widen the mint, not the App

Add the missing repositories and permissions to the token request that the job makes, keeping it as narrow as the job genuinely is. Nothing about the App changes, no installer has to accept anything, and the security posture stays where it was. If the mint asks for something the installation does not hold, then the App is the constraint and it is a different note.

How to check it worked

After the mint request is widened, the same reads show the repository in reach and the permission at the level the job needs, with no change to the App at all.

python3 github_token_reach.py --repo acme/api --repo acme/docs \
  --needs contents:read,issues:write --grant mint-response.json
# token reaches 1 repository, repository_selection=selected
# repos-out-of-reach: acme/docs is not in this token's repository set
# repair: add acme/docs to the repository list in the token request this job
# makes. The installation already covers it, so the App does not change.

# after widening the mint request
# reach-covers-the-job: this token reaches every repository the job needs
# and holds every permission at the level it asked for

The full code

One paginated GET for reach, one cheap GET per repository the job names, and no mint anywhere — minting is a write and this section does not write, so the script reads the token you already hold. The comparisons are pure and slightly fussy: repository names are matched case-insensitively because GitHub treats them that way and configuration files do not, permission levels are ranked so that read-where-write-is-needed counts as a shortfall, and the verdict has a state whose entire job is to say that the permission half could not be seen.

Get this script on GitHub Follow @allanninal Python and Node.js, with tests. Read only, it never writes. One of 101 GitHub API fixes, free and open source.
github_token_reach.py
"""Say whether an installation access token was narrowed below what a job needs.

Read only. One paginated GET for what the token reaches, one GET per
repository the job names. The token endpoint that would mint a wider token is
a write and is not called here: the script reads the token you already hold
and prints the mint request you should be making instead.

An installation access token can be minted for fewer repositories and fewer
permissions than the installation holds, by naming them in the mint request
body. The result is a 404 on a repository the App is plainly installed on,
from one code path, while every other path using the same App works.

There is a blind spot and the report states it. A token cannot report its own
permission map; the mint response echoed it back to your own code and no read
recovers it afterwards. Pass that saved response with --grant to make the
permission half exact, or the script reports it as unseen rather than passing.

Environment:

    GITHUB_INSTALLATION_TOKEN   the token the failing job holds
"""
import argparse
import json
import logging
import os
import sys

import requests

logging.basicConfig(level=logging.INFO, format="%(asctime)s %(levelname)s %(message)s")
log = logging.getLogger("github_token_reach")

API = "https://api.github.com"
UA = "github-token-reach/1.0"

RANK = {"none": 0, "read": 1, "write": 2, "admin": 3}


def rank(level):
    """A permission level as a comparable integer. Pure."""
    return RANK.get(str(level or "none").strip().lower(), 0)


def parse_needs(spec):
    """Turn contents:read,issues:write into a map. Pure.

    A bare name with no colon is taken as read, which is the level somebody
    means when they write down a permission without thinking about it.
    """
    out = {}
    for chunk in str(spec or "").split(","):
        item = chunk.strip()
        if not item:
            continue
        name, _, level = item.partition(":")
        name = name.strip().lower()
        if name:
            out[name] = (level.strip().lower() or "read")
    return out


def parse_grant(body):
    """Read a saved mint response into the facts it carries. Pure.

    Only three fields matter and any of them can be absent. permissions is
    None rather than an empty map when it is missing, because "this token was
    granted nothing" and "we did not see the grant" are opposite findings.
    """
    body = body if isinstance(body, dict) else {}
    permissions = body.get("permissions")
    repos = body.get("repositories")
    names = []
    if isinstance(repos, list):
        for repo in repos:
            if isinstance(repo, dict) and repo.get("full_name"):
                names.append(str(repo["full_name"]))
            elif isinstance(repo, str):
                names.append(repo)
    return {"permissions": permissions if isinstance(permissions, dict) else None,
            "repository_selection": body.get("repository_selection"),
            "repositories": names}


def repo_gap(reachable, needed):
    """Needed repositories the token cannot reach. Pure.

    Case-insensitive, because GitHub treats owner/name that way and the
    configuration file that lists them does not.
    """
    have = {str(r).strip().lower() for r in (reachable or [])}
    return [r for r in (needed or []) if str(r).strip().lower() not in have]


def permission_shortfall(granted, needed):
    """Needed permissions the token holds at a lower level. Pure.

    Returns None when the grant was never seen, which the caller reports as a
    blind spot rather than as a pass.
    """
    if granted is None:
        return None
    out = []
    for name, wanted in sorted((needed or {}).items()):
        have = (granted or {}).get(name)
        if rank(have) < rank(wanted):
            out.append((name, str(wanted), str(have) if have else "absent"))
    return out


def verdict(alive, missing_repos, shortfall, selection):
    """Turn reach, grant and need into a finding. Pure.

    Order matters: an unreachable repository is reported before a permission
    shortfall, because a 404 is the symptom people arrive with and fixing the
    permission first would leave them with the same 404.
    """
    if not alive:
        return ("token-not-alive",
                "GET /installation/repositories did not return 200, so this "
                "is not a working installation access token and the "
                "narrowing question does not arise yet.")
    if missing_repos:
        return ("repos-out-of-reach",
                "%s not in this token's repository set, so every call about "
                "them answers 404 whatever the App holds. Widen the "
                "repository list in the mint request."
                % ", ".join(missing_repos))
    if shortfall is None:
        return ("narrowing-not-visible",
                "every repository the job needs is reachable. The permission "
                "half cannot be checked: a token does not report its own "
                "permission map, and no saved mint response was supplied.")
    if shortfall:
        return ("permissions-below-need",
                "%s. The mint request asked for less than the job uses, which "
                "fails as 403 rather than as 404."
                % "; ".join("%s is %s, the job needs %s" % (n, h, w)
                            for n, w, h in shortfall))
    if str(selection or "").strip().lower() == "selected":
        return ("narrowed-but-sufficient",
                "this token is narrowed to a repository subset and the subset "
                "still covers the job. Nothing to change.")
    return ("reach-covers-the-job",
            "this token reaches every repository the job needs and holds "
            "every permission at the level it asked for.")


def repair(state, missing_repos, shortfall):
    """The change to make, in the mint request rather than in the App. Pure."""
    if state == "repos-out-of-reach":
        return ("add %s to the repository list in the token request this job "
                "makes. If the installation already covers them, the App does "
                "not change at all." % ", ".join(missing_repos))
    if state == "permissions-below-need":
        return ("raise %s in the permission map of the token request. If the "
                "installation does not hold it either, that is an App "
                "permission problem instead."
                % ", ".join("%s to %s" % (n, w) for n, w, _ in shortfall))
    if state == "narrowing-not-visible":
        return ("keep the mint response your code already receives, with the "
                "token value stripped, and pass it back in. It is the only "
                "place the granted permission map is ever visible.")
    return "nothing. This token is not the constraint."


def get(session, path):
    """One GET. Returns (status, json-or-None)."""
    url = API + path if path.startswith("/") else path
    r = session.get(url, timeout=30)
    try:
        body = r.json()
    except ValueError:
        body = None
    return r.status_code, body


def reachable_repositories(session, pages=10):
    """Every repository this token reaches. Returns (alive, names, selection)."""
    names, selection, alive = [], None, False
    for page in range(1, pages + 1):
        status, body = get(session,
                           "/installation/repositories?per_page=100&page=%d" % page)
        if status != 200 or not isinstance(body, dict):
            if page == 1:
                log.error("GET /installation/repositories returned %d; only an "
                          "installation access token can answer it", status)
            break
        alive = True
        selection = body.get("repository_selection", selection)
        rows = body.get("repositories") or []
        names.extend(str(r.get("full_name")) for r in rows
                     if isinstance(r, dict) and r.get("full_name"))
        if len(rows) < 100:
            break
    return alive, names, selection


def main():
    ap = argparse.ArgumentParser(description=__doc__)
    ap.add_argument("--repo", action="append", default=[],
                    help="a repository the job needs, as owner/name; repeatable")
    ap.add_argument("--needs", default="",
                    help="permissions the job uses, as contents:read,issues:write")
    ap.add_argument("--grant", default=None,
                    help="path to the saved mint response body, token stripped")
    args = ap.parse_args()

    token = os.environ.get("GITHUB_INSTALLATION_TOKEN") or \
        os.environ.get("GITHUB_TOKEN")
    if not token:
        log.error("set GITHUB_INSTALLATION_TOKEN to the token the failing job "
                  "holds. The narrowing is a property of that token and of no "
                  "other credential")
        return 2

    session = requests.Session()
    session.headers.update({
        "Authorization": "Bearer " + token,
        "Accept": "application/vnd.github+json",
        "X-GitHub-Api-Version": "2022-11-28",
        "User-Agent": UA,
    })

    alive, reach, selection = reachable_repositories(session)
    if alive:
        log.info("token reaches %d repository(ies), repository_selection=%s",
                 len(reach), selection or "unreported")

    # Confirming per repository rather than trusting the list, which can be
    # truncated by a pagination cap the caller did not notice.
    confirmed = []
    for name in args.repo:
        if not alive:
            break
        status, _ = get(session, "/repos/%s" % name.strip())
        log.info("GET /repos/%s returned %d", name.strip(), status)
        if status == 200:
            confirmed.append(name.strip())
    reach_all = sorted({*reach, *confirmed})

    grant = {"permissions": None, "repository_selection": selection,
             "repositories": []}
    if args.grant:
        try:
            with open(args.grant, encoding="utf-8") as fh:
                grant = parse_grant(json.load(fh))
        except (OSError, ValueError) as exc:
            log.error("could not read the saved mint response: %s", exc)
        else:
            selection = grant.get("repository_selection") or selection

    missing = repo_gap(reach_all, args.repo)
    shortfall = permission_shortfall(grant["permissions"], parse_needs(args.needs))
    state, detail = verdict(alive, missing, shortfall, selection)
    log.info("%s: %s", state, detail)
    log.info("repair: %s", repair(state, missing, shortfall))

    print(json.dumps({"reachable": reach_all, "repository_selection": selection,
                      "needed_repositories": args.repo,
                      "missing_repositories": missing,
                      "permission_shortfall": shortfall,
                      "state": state}, indent=2, default=str))
    return 1 if state in ("repos-out-of-reach", "permissions-below-need") else 0


if __name__ == "__main__":
    sys.exit(main())
github-token-reach.mjs
/**
 * Say whether an installation access token was narrowed below what a job needs.
 *
 * Read only. One paginated GET for what the token reaches, one GET per
 * repository the job names. The token endpoint that would mint a wider token
 * is a write and is not called here: the script reads the token you already
 * hold and prints the mint request you should be making instead.
 *
 * A token cannot report its own permission map. The mint response echoed it
 * back to your own code and no read recovers it afterwards, so pass that saved
 * response as the third argument to make the permission half exact.
 *
 * Environment:
 *   GITHUB_INSTALLATION_TOKEN   the token the failing job holds
 */
import { readFile } from 'node:fs/promises';

const API = 'https://api.github.com';
const UA = 'github-token-reach/1.0';

export const RANK = { none: 0, read: 1, write: 2, admin: 3 };

/** A permission level as a comparable integer. Pure. */
export function rank(level) {
  const key = String(level ?? 'none').trim().toLowerCase();
  return Object.prototype.hasOwnProperty.call(RANK, key) ? RANK[key] : 0;
}

/** Turn contents:read,issues:write into a map. Pure. Bare names mean read. */
export function parseNeeds(spec) {
  const out = {};
  for (const chunk of String(spec ?? '').split(',')) {
    const item = chunk.trim();
    if (!item) continue;
    const at = item.indexOf(':');
    const name = (at === -1 ? item : item.slice(0, at)).trim().toLowerCase();
    const level = (at === -1 ? '' : item.slice(at + 1)).trim().toLowerCase();
    if (name) out[name] = level || 'read';
  }
  return out;
}

/** Read a saved mint response into the facts it carries. Pure. */
export function parseGrant(body) {
  const row = body && typeof body === 'object' ? body : {};
  const permissions = row.permissions && typeof row.permissions === 'object'
    ? row.permissions : null;
  const names = [];
  if (Array.isArray(row.repositories)) {
    for (const repo of row.repositories) {
      if (repo && typeof repo === 'object' && repo.full_name) names.push(String(repo.full_name));
      else if (typeof repo === 'string') names.push(repo);
    }
  }
  return {
    permissions,
    repository_selection: row.repository_selection ?? null,
    repositories: names,
  };
}

/** Needed repositories the token cannot reach. Pure. Case-insensitive. */
export function repoGap(reachable, needed) {
  const have = new Set((reachable ?? []).map((r) => String(r).trim().toLowerCase()));
  return (needed ?? []).filter((r) => !have.has(String(r).trim().toLowerCase()));
}

/**
 * Needed permissions the token holds at a lower level. Pure.
 * null when the grant was never seen, which is a blind spot and not a pass.
 */
export function permissionShortfall(granted, needed) {
  if (granted === null || granted === undefined) return null;
  const out = [];
  for (const name of Object.keys(needed ?? {}).sort()) {
    const wanted = needed[name];
    const have = granted[name];
    if (rank(have) < rank(wanted)) {
      out.push([name, String(wanted), have ? String(have) : 'absent']);
    }
  }
  return out;
}

/** Turn reach, grant and need into a finding. Pure. */
export function verdict(alive, missingRepos, shortfall, selection) {
  if (!alive) {
    return ['token-not-alive',
      'GET /installation/repositories did not return 200, so this is not a ' +
      'working installation access token and the narrowing question does not ' +
      'arise yet.'];
  }
  if (missingRepos && missingRepos.length) {
    return ['repos-out-of-reach',
      `${missingRepos.join(', ')} not in this token's repository set, so ` +
      'every call about them answers 404 whatever the App holds. Widen the ' +
      'repository list in the mint request.'];
  }
  if (shortfall === null || shortfall === undefined) {
    return ['narrowing-not-visible',
      'every repository the job needs is reachable. The permission half ' +
      'cannot be checked: a token does not report its own permission map, ' +
      'and no saved mint response was supplied.'];
  }
  if (shortfall.length) {
    return ['permissions-below-need',
      `${shortfall.map(([n, w, h]) => `${n} is ${h}, the job needs ${w}`).join('; ')}. ` +
      'The mint request asked for less than the job uses, which fails as 403 ' +
      'rather than as 404.'];
  }
  if (String(selection ?? '').trim().toLowerCase() === 'selected') {
    return ['narrowed-but-sufficient',
      'this token is narrowed to a repository subset and the subset still ' +
      'covers the job. Nothing to change.'];
  }
  return ['reach-covers-the-job',
    'this token reaches every repository the job needs and holds every ' +
    'permission at the level it asked for.'];
}

/** The change to make, in the mint request rather than in the App. Pure. */
export function repair(state, missingRepos, shortfall) {
  if (state === 'repos-out-of-reach') {
    return `add ${(missingRepos ?? []).join(', ')} to the repository list in ` +
      'the token request this job makes. If the installation already covers ' +
      'them, the App does not change at all.';
  }
  if (state === 'permissions-below-need') {
    return `raise ${(shortfall ?? []).map(([n, w]) => `${n} to ${w}`).join(', ')} ` +
      'in the permission map of the token request. If the installation does ' +
      'not hold it either, that is an App permission problem instead.';
  }
  if (state === 'narrowing-not-visible') {
    return 'keep the mint response your code already receives, with the token ' +
      'value stripped, and pass it back in. It is the only place the granted ' +
      'permission map is ever visible.';
  }
  return 'nothing. This token is not the constraint.';
}

async function get(token, path) {
  const url = path.startsWith('/') ? API + path : path;
  const res = await fetch(url, {
    headers: {
      Authorization: `Bearer ${token}`,
      Accept: 'application/vnd.github+json',
      'X-GitHub-Api-Version': '2022-11-28',
      'User-Agent': UA,
    },
  });
  let body = null;
  try { body = await res.json(); } catch { body = null; }
  return { status: res.status, body };
}

async function reachableRepositories(token, pages = 10) {
  const names = [];
  let selection = null;
  let alive = false;
  for (let page = 1; page <= pages; page += 1) {
    const { status, body } = await get(token,
      `/installation/repositories?per_page=100&page=${page}`);
    if (status !== 200 || !body || typeof body !== 'object') {
      if (page === 1) {
        console.error(`GET /installation/repositories returned ${status}; ` +
          'only an installation access token can answer it');
      }
      break;
    }
    alive = true;
    selection = body.repository_selection ?? selection;
    const rows = body.repositories ?? [];
    for (const r of rows) if (r && r.full_name) names.push(String(r.full_name));
    if (rows.length < 100) break;
  }
  return { alive, names, selection };
}

async function main() {
  const token = process.env.GITHUB_INSTALLATION_TOKEN ?? process.env.GITHUB_TOKEN;
  if (!token) {
    console.error('set GITHUB_INSTALLATION_TOKEN to the token the failing job ' +
      'holds. The narrowing is a property of that token and of no other credential');
    process.exitCode = 2;
    return;
  }
  const needed = (process.argv[2] ?? '').split(',').map((s) => s.trim()).filter(Boolean);
  const needs = parseNeeds(process.argv[3] ?? '');
  const grantPath = process.argv[4] ?? null;

  const { alive, names, selection: seen } = await reachableRepositories(token);
  let selection = seen;
  if (alive) {
    console.log(`token reaches ${names.length} repository(ies), ` +
      `repository_selection=${selection ?? 'unreported'}`);
  }

  // Confirming per repository rather than trusting the list, which can be
  // truncated by a pagination cap the caller did not notice.
  const confirmed = [];
  for (const name of alive ? needed : []) {
    const { status } = await get(token, `/repos/${name}`);
    console.log(`GET /repos/${name} returned ${status}`);
    if (status === 200) confirmed.push(name);
  }
  const reachAll = [...new Set([...names, ...confirmed])].sort();

  let grant = { permissions: null, repository_selection: selection, repositories: [] };
  if (grantPath) {
    try {
      grant = parseGrant(JSON.parse(await readFile(grantPath, 'utf8')));
      selection = grant.repository_selection ?? selection;
    } catch (err) {
      console.error(`could not read the saved mint response: ${err.message}`);
    }
  }

  const missing = repoGap(reachAll, needed);
  const shortfall = permissionShortfall(grant.permissions, needs);
  const [state, detail] = verdict(alive, missing, shortfall, selection);
  console.log(`${state}: ${detail}`);
  console.log(`repair: ${repair(state, missing, shortfall)}`);

  console.log(JSON.stringify({
    reachable: reachAll,
    repository_selection: selection,
    needed_repositories: needed,
    missing_repositories: missing,
    permission_shortfall: shortfall,
    state,
  }, null, 2));
  process.exitCode = ['repos-out-of-reach', 'permissions-below-need'].includes(state) ? 1 : 0;
}

// Only run when invoked directly, so importing this module from the test file
// does not execute main(), fail on the missing token and set an exit code that
// fails the suite even as every test passes.
if (import.meta.url === `file://${process.argv[1]}`) {
  main().catch((err) => { console.error(err.message); process.exitCode = 2; });
}

Add a test

The test this script exists for is the one that distinguishes no shortfall from no visibility: an empty list of missing permissions and an unseen grant are the same shape in a careless implementation and opposite findings in a useful one. The rest pin the ordering, since a reader arriving with a 404 must be told about the unreachable repository before anything else, and the small cruelties of real input: repository names in the wrong case, a permission written with no level, a mint response with no permissions block.

test_github_token_reach.py
from github_token_reach import (
    parse_grant, parse_needs, permission_shortfall, rank, repair, repo_gap,
    verdict,
)

MINT = {"expires_at": "2026-08-30T13:00:00Z",
        "permissions": {"contents": "read", "metadata": "read"},
        "repository_selection": "selected",
        "repositories": [{"full_name": "acme/api"}]}


def test_a_bare_permission_name_means_read():
    assert parse_needs("contents, issues:write") == {"contents": "read",
                                                     "issues": "write"}
    assert parse_needs("") == {}
    assert parse_needs("  ,  ") == {}


def test_levels_are_ranked_rather_than_compared_as_strings():
    assert rank("write") > rank("read") > rank(None)
    assert rank("nonsense") == 0


def test_a_mint_response_is_read_for_the_three_fields_that_matter():
    grant = parse_grant(MINT)
    assert grant["permissions"] == {"contents": "read", "metadata": "read"}
    assert grant["repository_selection"] == "selected"
    assert grant["repositories"] == ["acme/api"]


def test_a_mint_response_with_no_permissions_block_is_unseen_not_empty():
    assert parse_grant({"repository_selection": "all"})["permissions"] is None
    assert parse_grant(None)["permissions"] is None


def test_repository_names_match_regardless_of_case():
    assert repo_gap(["acme/API"], ["Acme/api"]) == []
    assert repo_gap(["acme/api"], ["acme/api", "acme/docs"]) == ["acme/docs"]


def test_an_unseen_grant_is_not_a_permission_pass():
    assert permission_shortfall(None, {"issues": "write"}) is None
    assert permission_shortfall({}, {"issues": "write"}) == [("issues", "write", "absent")]


def test_read_where_write_is_needed_is_a_shortfall():
    assert permission_shortfall({"issues": "read"}, {"issues": "write"}) == \
        [("issues", "write", "read")]
    assert permission_shortfall({"issues": "write"}, {"issues": "read"}) == []


def test_an_unreachable_repository_is_reported_before_a_permission_shortfall():
    state, detail = verdict(True, ["acme/docs"], [("issues", "write", "read")],
                            "selected")
    assert state == "repos-out-of-reach"
    assert "acme/docs" in detail


def test_a_permission_shortfall_names_both_levels():
    state, detail = verdict(True, [], [("issues", "write", "read")], "all")
    assert state == "permissions-below-need"
    assert "issues is read, the job needs write" in detail


def test_an_unseen_grant_gets_its_own_state_rather_than_a_clean_bill():
    state, detail = verdict(True, [], None, "all")
    assert state == "narrowing-not-visible"
    assert "does not report its own permission map" in detail


def test_a_narrowed_token_that_still_covers_the_job_is_not_a_fault():
    assert verdict(True, [], [], "selected")[0] == "narrowed-but-sufficient"


def test_a_wide_token_that_covers_the_job_is_clean():
    assert verdict(True, [], [], "all")[0] == "reach-covers-the-job"


def test_a_dead_token_is_never_reported_as_a_narrowing():
    state, detail = verdict(False, ["acme/docs"], None, None)
    assert state == "token-not-alive"
    assert "does not arise yet" in detail


def test_the_repair_points_at_the_mint_request_and_not_at_the_app():
    text = repair("repos-out-of-reach", ["acme/docs"], None)
    assert "token request" in text
    assert "the App does not change" in text
    assert "mint response" in repair("narrowing-not-visible", [], None)
    assert repair("reach-covers-the-job", [], []) == "nothing. This token is not the constraint."
github-token-reach.test.mjs
import { test } from 'node:test';
import assert from 'node:assert/strict';
import {
  parseGrant, parseNeeds, permissionShortfall, rank, repair, repoGap, verdict,
} from './github-token-reach.mjs';

const MINT = {
  expires_at: '2026-08-30T13:00:00Z',
  permissions: { contents: 'read', metadata: 'read' },
  repository_selection: 'selected',
  repositories: [{ full_name: 'acme/api' }],
};

test('a bare permission name means read', () => {
  assert.deepEqual(parseNeeds('contents, issues:write'),
    { contents: 'read', issues: 'write' });
  assert.deepEqual(parseNeeds(''), {});
  assert.deepEqual(parseNeeds('  ,  '), {});
});

test('levels are ranked rather than compared as strings', () => {
  assert.ok(rank('write') > rank('read'));
  assert.ok(rank('read') > rank(null));
  assert.equal(rank('nonsense'), 0);
});

test('a mint response is read for the three fields that matter', () => {
  const grant = parseGrant(MINT);
  assert.deepEqual(grant.permissions, { contents: 'read', metadata: 'read' });
  assert.equal(grant.repository_selection, 'selected');
  assert.deepEqual(grant.repositories, ['acme/api']);
});

test('a mint response with no permissions block is unseen not empty', () => {
  assert.equal(parseGrant({ repository_selection: 'all' }).permissions, null);
  assert.equal(parseGrant(null).permissions, null);
});

test('repository names match regardless of case', () => {
  assert.deepEqual(repoGap(['acme/API'], ['Acme/api']), []);
  assert.deepEqual(repoGap(['acme/api'], ['acme/api', 'acme/docs']), ['acme/docs']);
});

test('an unseen grant is not a permission pass', () => {
  assert.equal(permissionShortfall(null, { issues: 'write' }), null);
  assert.deepEqual(permissionShortfall({}, { issues: 'write' }),
    [['issues', 'write', 'absent']]);
});

test('read where write is needed is a shortfall', () => {
  assert.deepEqual(permissionShortfall({ issues: 'read' }, { issues: 'write' }),
    [['issues', 'write', 'read']]);
  assert.deepEqual(permissionShortfall({ issues: 'write' }, { issues: 'read' }), []);
});

test('an unreachable repository is reported before a permission shortfall', () => {
  const [state, detail] = verdict(true, ['acme/docs'], [['issues', 'write', 'read']], 'selected');
  assert.equal(state, 'repos-out-of-reach');
  assert.match(detail, /acme\/docs/);
});

test('a permission shortfall names both levels', () => {
  const [state, detail] = verdict(true, [], [['issues', 'write', 'read']], 'all');
  assert.equal(state, 'permissions-below-need');
  assert.match(detail, /issues is read, the job needs write/);
});

test('an unseen grant gets its own state rather than a clean bill', () => {
  const [state, detail] = verdict(true, [], null, 'all');
  assert.equal(state, 'narrowing-not-visible');
  assert.match(detail, /does not report its own permission map/);
});

test('a narrowed token that still covers the job is not a fault', () => {
  assert.equal(verdict(true, [], [], 'selected')[0], 'narrowed-but-sufficient');
});

test('a wide token that covers the job is clean', () => {
  assert.equal(verdict(true, [], [], 'all')[0], 'reach-covers-the-job');
});

test('a dead token is never reported as a narrowing', () => {
  const [state, detail] = verdict(false, ['acme/docs'], null, null);
  assert.equal(state, 'token-not-alive');
  assert.match(detail, /does not arise yet/);
});

test('the repair points at the mint request and not at the app', () => {
  const text = repair('repos-out-of-reach', ['acme/docs'], null);
  assert.match(text, /token request/);
  assert.match(text, /the App does not change/);
  assert.match(repair('narrowing-not-visible', [], null), /mint response/);
  assert.equal(repair('reach-covers-the-job', [], []),
    'nothing. This token is not the constraint.');
});

FAQ

Why a 404 and not a 403 when the repository is out of reach?

Because GitHub answers 404 rather than 403 whenever a credential is not entitled to know that a private resource exists. Returning 403 would confirm the repository is there, which leaks the thing the permission model is protecting. The consequence for debugging is that a narrowed token and a misspelled repository name produce exactly the same response, so the first hour usually goes on spelling, renames and archived repositories, all of which come back fine. Ask the token what it reaches and the ambiguity disappears.

Is this the same as an installation that only covers some repositories?

No, and the two are easy to confuse because both end in a 404 on a repository you can see in the browser. There the installation itself is narrow, so every token minted from it is narrow in the same way and the fix is to add repositories to the installation. Here the installation is wide and one token was cut down when it was minted, so other jobs using the same App work perfectly and the fix is four lines of your own minting code. The discriminator is whether other code paths reach the repository.

Why can the script not just read the token's permissions?

Because nothing returns them. GET /installation/repositories answers the repository half exactly, and there is no equivalent read for the permission map a token was minted with. It appears once, in the response your own minting code received, and after that it is gone. That is why the script has a state whose only job is to say the permission half was not visible, and why the practical advice is to keep that response, with the token value stripped out, wherever you keep your logs.

Should we stop narrowing tokens then?

No. Narrowing is the right default and this note is not an argument against it; a job that touches one repository should hold a token that reaches one repository, so that a leak is bounded. The failure is drift, not the practice: the narrowest correct token for the job as it was written is too narrow for the job as it is now, and nothing tells you when that line is crossed. Run this check in the job's own test suite, with the repositories and permissions it declares, and the drift becomes a failing test rather than a 404 in production.

Widening the mint request did not help. What now?

Then the installation really is the constraint, because the mint request can only intersect with what the installation holds and can never exceed it. Check whether the installation covers the repository at all, and whether the App holds the permission you asked the token to carry. Those are two different published notes, and the useful thing about having run this check first is that you now know the narrowing was not in your own minting code, which is the cheapest of the three things to rule out.

Related field notes

Sources

Every figure in this note is traced to one of these. Prices are list rates and change — check them for your own region before acting.

Stuck on a tricky one?

If your setup is misbehaving in a way this note does not cover, message me on LinkedIn with what you are seeing.
